FC-TSAI-0410 Field Termination Assembly Honeywell

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (15 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Honeywell

  • Type:

    FTA Module

  • Tags Fta module

About the Product

Honeywell TSAI-0410 Safe Analog Input Field Termination Assembly

The FS-TSAI-0410 and FC-TSAI-0410 modules deliver reliable interface capabilities for safe analog input signals. This field termination assembly ensures secure connection between field wiring and safety-rated analog input modules.

Key Features

  • Four safe analog input channels for critical measurements
  • Range selection capability for flexible configuration
  • Universal DIN rail mounting for easy installation
  • Screw terminals for secure field wiring connections
  • Compatible with BSAI-04x and BSDIL-0426 range boards
  • Redundant SAI-0410 module connectivity

Technical Specifications

  • Models: FS-TSAI-0410, FC-TSAI-0410
  • Channels: 4 independent analog inputs
  • Weight:2kg
  • Maximum Voltage: 50V DC protection rating
  • Overvoltage Category: 3 (IEC 1010)
  • Current Range: 0(4)-20 mA with 50mA maximum
  • Voltage Range: 0(2)-10 V with 10V maximum
  • Safety Rating: Safe analog input capability

System Integration

  • Interfaces with SICC-0001/Lx system cables
  • Connects to redundant SAI-0410 analog input modules
  • Four-channel connectivity per module pair
  • Range selection per module configuration
  • Field wiring to safety system bridge

Configuration Options

  • BSAI-04x range selection board compatibility
  • BSDIL-0426 configuration board support
  • 0(4)-20 mA current input capability
  • 0(2)-10 V voltage input capability
  • Per-module range setting flexibility

Wiring & Installation

  • Mounting: DIN EN rails TS32/TS35
  • Module Dimensions: 60 × 70 × 58 mm compact size
  • Rail Length: 61 mm required space
  • Terminals: Screw type with 2.5 mm² capacity
  • Strip Length: 7 mm recommended
  • Torque: 0.5 Nm tightening specification

Electrical Safety

  • 50V DC maximum voltage rating
  • Overvoltage category 3 compliance
  • Safe analog input functionality
  • Industrial safety standards adherence
  • Robust electrical isolation

Applications

  • Safety instrumented system analog inputs
  • Process variable monitoring
  • Critical measurement applications
  • Industrial safety system interfaces
  • Analog sensor signal conditioning

Certifications & Compliance

  • CE, TUV, UL, CSA, FM safety certified
  • IEC 1010 standard compliance
  • Safety system compatibility
  • Global market approvals
