AP3500S2-Z1 Key Specifications Dynamic Sensitivity: ± 5% at 25°C, 500 mV/g Acceleration Range: 10 g peak Weight: 0.148kg Frequency Response: ± 10%: 0.4–1 500 Hz ± 3 dB: 0.2–3 700 Hz Resonant Frequency: 18 kHz Transverse Sensitivity: Max ± 7% of axial Temperature Response: –50°C: –8% +120°C: +5% Voltage Source: 18–30 Vdc Current Drive: 2–10 mA (regulated) Broadband Noise: 12 μg...

AP3500T2-Z1 Product Overview: Manufacturer: Bently Nevada Model: Case Mounted Accelerometer Weight : 142 grams Condition: New & Original in Factory Packing Factory Warranty: 12 months Core Dynamic Specifications: Sensitivity ± 5 % @ 25 °C: 500 mV/g Acceleration Range: 10 g peak Amplitude Nonlinearity: 1 % Frequency Response ± 10 %: 0.4 – 1 000 Hz Frequency Response ± 3 dB:...

Bently Nevada AS3100S2‑Z2 Case Mounted Accelerometer Suffix Breakdown: AS3100: Series identifier S2: Side‑exit 2‑pin MIL‑C‑5015 connector Z2: Hermetic sealing and case isolation Core Dynamic Specifications: Sensitivity ±5 % @ 25 °C: 100 mV/g Acceleration range: 80 g peak Amplitude nonlinearity: 1 % Freq. resp. ±10 %: 1 – 5 000 Hz Freq. resp. ±3 dB: 0.5 – 10 000 Hz Resonant frequency:...

Product Overview: Manufacturer: Bently Nevada Part Number: AM3100T2‑Z2 Core Dynamic Specifications: Sensitivity ±5% @ 25 °C: 100 mV/g Acceleration Range: 80 g peak Amplitude Nonlinearity: 1 % Frequency Response ±10%: 0.7–9 000 Hz Frequency Response ±3 dB: 0.4–14 000 Hz Resonant Frequency: 30 kHz Transverse Sensitivity ≤ ±5 % Temperature Response at –55 °C: –20 % Temperature Response at +120 °C:...

Bently Nevada 200152-04-10 Accelerometer Interface Standard Cable Product Identification Model Number: 200152-04-10 Product Type: Accelerometer Interface Standard Cable with Connector on Accelerometer End Only Ordering Breakdown Base Model: 200151 - Accelerometer Interface Standard Cable, Connector on Accelerometer End Only Cable Length Option: -04 =...

Bently Nevada 200152-15-CN Accelerometer Interface Standard Cable Product Overview Model Number: 200152-15-CN Product Type: Accelerometer Interface Standard Cable with Connector on Accelerometer End Only Part of Bently Nevada's trusted vibration monitoring solutions, this cable ensures consistent performance in demanding conditions. Ordering Information Base Model:...

Manufacturer: Bently Nevada Product Number: 200150-23-05 Product Type: General Purpose Accelerometer for Trendmaster 2000 or Trendmaster Pro Systems Country of Origin: Made in U.S.A Mounting Stud Option 23: 3/8-24 to M16x2.0, 1-3/8 inch hex plate stud Approval Code 05: Certified for CSA, ATEX, and...

Model Number Breakdown 200150-22-05 Base Model: 200150 Mount Option 22: 3/8‑24 OD to M8×1.25 ID, 1‑3/8″ hex plate stud Approval Code 05: CSA, ATEX, IECEx certified Key Performance Highlights Sensitivity @ 80 Hz: 10.2 mV/(m/s²) (±12 %) Measurement Range: ±245 m/s² (±25 g) Frequency Response: 10 – 1000 Hz (600 – 60 000 cpm) Resonant Frequency: > 20 kHz...

Model Number Breakdown 200150-21-05 Base Model: 200150 Mount Option 21: 3/8‑24 OD to M6×1 ID, 1‑3/8″ hex plate stud Approval Code 05: CSA, ATEX, IECEx certified Key Performance Highlights Sensitivity @ 80 Hz: 10.2 mV/(m/s²) (±12 %) Measurement Range: ±245 m/s² (±25 g) Frequency Response: 10 – 1000 Hz (600 – 60 000 cpm) Resonant Frequency: > 20 kHz...

200150-20-05 Bently Nevada Electrical Characteristics Sensitivity @ 80 Hz: 10.2 mV/(m/s²) (100 mV/g, ±12%) Measurement Range: ±245 m/s² (±25 g) Frequency Range: 10 Hz to 1 000 Hz (600 to 60 000 cpm) Resonant Frequency: > 20 kHz (> 1 200 kcpm) Linearity: ±2% (1 to 10 g pk) Transverse Sensitivity: ≤ 7% Excitation Voltage: 4.7 – 5.5 V DC Quiescent Current: < 800 µA Output Bias Voltage:...

Bently Nevada Accelerometer Model: 200150-19-05 Electrical Performance: • Sensitivity: 10.2 mV/(m/s²) (100 mV/g)• Measurement Range: ±245 m/s² (±25 g)• Velocity Response: 14.7 mm/s² (1.5 mg)• Frequency Response: 10 to 1000 Hz (600 to 60,000 cpm)• Mounted Resonant Frequency: >20 kHz• Amplitude Linearity: ±2% (1–10g...

Core Specifications Frequency Response: 10 Hz – 1 kHz (600 – 60 000 cpm) Resonant Frequency: >20 kHz (>1 200 kcpm) Amplitude Linearity: ±2 % (1 – 10 g pk) Transverse Sensitivity: ≤7 % Settling Time: ≤300 ms (5 % of bias) Excitation Voltage: 4.7 – 5.5 V DC Quiescent Current: <800 µA Output Bias Voltage: +2.5 ± 0.23 V DC Mounting Stud: 3/8‑24 to M8×1, 1‑3/8″ hex plate (option 18) Approvals: CSA, ATEX,...

200150-17-05 Key Specifications Frequency Response: 10 Hz to 1 kHz (600 to 60 000 cpm) Resonant Frequency: >20 kHz (>1 200 kcpm) Amplitude Linearity: ±2 % (1 to 10 g pk) Transverse Sensitivity: ≤7 % Settling Time: ≤300 ms (within 5 % of bias) Excitation Voltage: 4.7–5.5 V DC Quiescent Current: <800 µA Output Bias: +2.5 ± 0.23 V DC Mounting Stud: 3/8‑24 to 3/8‑16 UNC 1‑3/8″ hex plate (option 17) Approvals: CSA, ATEX, IECEx...

Manufacturer: Bently Nevada Product No: 200150-16-05 Product Type: General Purpose Accelerometer for Trendmaster 2000 or Trendmaster Pro Systems Country of Origin: Made in U.S.A (Certificate of Origin available upon request) Application: Suitable for general-purpose vibration monitoring applications when used with the ProTIM acceleration-to-velocity channel...

Manufacturer: Bently Nevada Product Number: 200150-14-05 Vibration and Frequency Characteristics: Frequency Range: 10 Hz to 1000 Hz (600 to 60,000 cpm) ±10% Mounted Resonant Frequency: >20 kHz (>1,200,000 cpm) Amplitude Linearity: ±2% from 1 to 10 g peak Transverse Sensitivity: ≤7% Settling Time: ≤300...

Manufacturer: Bently Nevada Product Number: 200150-13-05 Electrical Performance: Sensitivity: 10.2 mV/(m/s²) or 100 mV/g @ 80 Hz ±12% Measurement Range: ±245 m/s² (±25 g) Output Bias Voltage: +2.5 Vdc ±0.23 Vdc Excitation Voltage: 4.7 to 5.5 Vdc Quiescent Current: Less than 800 µA Polarity:...

Manufacturer: Bently Nevada Product Number: 200150-12-05 Product Type: General Purpose Trendmaster 2000 / Trendmaster Pro Accelerometer Country of Origin: Made in U.S.A (Certificate of Origin available) Mounting Stud Option: 12 = 3/8-24 to 1/4-20 UNC, 3/4 inch hex stud Approval Code: 05 = CSA,...

Model Configuration 200150-11-05 200150: Accelerometer series-11: Stud adapter (3/8‑24 to 1¼ NPT, 1¾″ hex)-05: Approvals (CSA, ATEX, IECEx) Performance Highlights Inherent Noise: <0.22 mg RMS Dynamic Range: 119 dB Cross‑Axis Sensitivity: ≤6% Signal‑to‑Noise Ratio: 64 dB at 80 Hz Calibration Uncertainty: ±1% full scale Electrical & Signal Integrity Element Capacitance:...

Model Configuration 200150-10-05 200150: Accelerometer series-10: Stud adapter (3/8‑24 to 1 NPT, 1⅜″ hex)-05: Approvals (CSA, ATEX, IECEx) Advanced Electrical Characteristics Stray Capacitance: 50 pF typical (new data) Insulation Resistance: >2 500 MΩ at 50 V DC (new data) Power‑Supply Variation: <0.5% output change per 0.1 V drift (new data) Phase...

200150-08-05 Core Specifications  Sensitivity (80 Hz ±12%): 10.2 mV/(m/s²) (100 mV/g) Resonance: >20 kHz (>1 200 kcpm) Inherent Noise: <0.2 mg RMS (new data) Transverse Sensitivity: ≤7% Settling Time: ≤300 ms to 5% bias Output Impedance: 100 Ω typical Temperature Coefficient: <0.02%/°C (new data) Environmental & Performance Operating Temp: –40 °C to +105 °C (–40 °F to...
