Bently Nevada 200152-15-CN Accelerometer Standard Cable

Bently Nevada 200152-15-CN Accelerometer Interface Standard Cable

Product Overview

Model Number: 200152-15-CN

Product Type: Accelerometer Interface Standard Cable with Connector on Accelerometer End Only

Part of Bently Nevada's trusted vibration monitoring solutions, this cable ensures consistent performance in demanding conditions.

Ordering Information

Base Model: 200151 - Accelerometer Interface Standard Cable, Connector on Accelerometer End Only

Cable Length Option: -15 = 15 meters

Coupling Nut Option: -CN = Country Specific

Technical Specifications

Minimum Bend Radius: 73.7 mm (2.9 inches)

Operating Temperature Range: -20 ºC to +100 ºC (-4 ºF to +212 ºF)

Extreme Temperature Note: Usable at temperatures below -20 ºC (-4 ºF) only if installation avoids flexing or bending.

Cable Construction

Type: 4-conductor, 22 AWG with braided shield and drain wire

Shield Coverage: Minimum 85%

Outer Jacket: Durable PVC for enhanced environmental protection

Coupling Nuts: Nickel-plated for corrosion resistance

Environmental Protection

IP Rating: IP67 - Provides full protection against dust and temporary water immersion

Connector Design: Molded directly to the cable for additional durability

Enhanced Moisture Protection: Integrated DC4 electrical insulating compound inside connectors resists moisture during rapid thermal changes

Additional Technical Data

Extended Temperature Range: -55 ºC to +121 ºC (-67 ºF to +250 ºF) for certain components

Complete Cure Time: 24 hours after installation to ensure optimal performance

Electrical Performance: Supports low-noise signal transmission, ensuring reliable vibration data

Maximum Signal Integrity Distance: Tested up to 15 meters without signal degradation under standard conditions

Service Life Expectancy: Designed for over 5 million flex cycles in static installations

Shelf Life: 12 months when stored under recommended conditions
