200152-04-10 Bently Nevada - Accelerometer Standard Cable

Bently Nevada 200152-04-10 Accelerometer Interface Standard Cable

Product Identification

Model Number: 200152-04-10

Product Type: Accelerometer Interface Standard Cable with Connector on Accelerometer End Only

Ordering Breakdown

Base Model: 200151 - Accelerometer Interface Standard Cable, Connector on Accelerometer End Only

Cable Length Option: -04 = 4.0 meters

Coupling Nut Option: -10 = Enhanced Coupling Nut (Better grip for tightening on accelerometer side only)

Technical Specifications

Minimum Bend Radius: 73.7 mm (2.9 inches)

Operating Temperature Range: -20 ºC to +100 ºC (-4 ºF to +212 ºF)

Extreme Temperature Application: Suitable for lower temperatures if the cable remains stationary; flexing below -20 ºC (-4 ºF) may cause damage

Cable Construction Details

Configuration: 4-conductor, 22 AWG for stable signal transmission

Braided Shield: 85% minimum coverage with drain wire for EMI protection

Outer Jacket: Tough, industrial-grade PVC for durability

Coupling Nuts: Nickel-plated, corrosion-resistant with enhanced design on accelerometer end

Sealing and Protection

IP Rating: IP67 for dust and water ingress protection

Connector Design: Molded directly to cable for durability and strain relief

Additional Protection: DC4 electrical insulating compound applied within connectors to prevent moisture intrusion during rapid temperature shifts

Enhanced Performance Parameters

Extended Temperature Endurance: -55 ºC to +121 ºC (-67 ºF to +250 ºF) for specific materials

Cure Time: Full performance achieved after 24 hours of installation

Flexibility Rating: Over 5 million cycles in non-moving applications

Maximum Cable Length Efficiency: Up to 4.0 meters without compromising signal integrity

Shelf Life: 12 months under controlled storage conditions
