5094-OB32 Digital Output Module | 32-Point

Allen-Bradley 5094-OB32 32-Point Digital Output Module

Core Technical Specifications

Output Type: Sourcing

Number of Channels: 32 points

Operating Voltage Range: 18 to 32 V DC

On-State Current per Channel: 1.0 mA

Maximum Voltage Drop: 0.25 V DC

Backplane Power Consumption: 95 mA

Overvoltage Protection: 36 V DC fused

Operating Temperature: 0 to 60 °C

Heat Dissipation: 13.65 BTU/hr

Response Time: 0.1 ms

Isolation Voltage: 500 V AC

Weight:0.2kg

Industrial Applications & Solutions

This module controls high speed packaging machines. It sends signals to solenoid valves and actuators. It helps in automotive assembly lines for precise control. The module manages material handling systems like conveyor belts. It is perfect for controlling sorting machines in distribution centers. The device operates robotic arm tools in manufacturing cells. It is used in water treatment plants to control pump motors.

Solving Key Industrial Problems

The module detects short circuits quickly to prevent damage. It finds open load conditions to avoid machine downtime. The built in fuse protects against voltage spikes. It works in tight spaces saving valuable panel room. The module handles dirty power conditions well. It operates in warm environments where other devices fail. The status LEDs show problems fast for easy troubleshooting.

What You Get In The Box

One 5094-OB32 digital output module. One set of printed installation instructions. This product does not include any certificates. Warranty is valid for 12 months from the purchase date.

Easy Installation Guide

Mount the module on a standard DIN rail. Connect the module to the FLEX 5000 I/O adapter. Use a 24V DC power supply for actuator power. Wire your field devices to the output terminals. Ensure the operating temperature is within range. Power up the system and check the status LEDs.

Compatible Systems

Works with Allen-Bradley FLEX 5000 series I/O adapters. Connects to ControlLogix 5570 and 5580 controllers. Compatible with CompactLogix 5370 and 5380 controllers. Supports Studio 5000 Logix Designer software. Uses CIP Sync for precise time synchronization.
