330910-05-11-10-02-00 Bently Nevada 3300 NSv Proximity Probe

Bently Nevada 3300 NSv Proximity Probe Overview

Key Technical Specifications

• Model Configuration: This 330910 probe features an M10X1 threaded armor option with 50 mm unthreaded length and a 110 mm overall case length for specific mounting requirements.
• Electrical Performance: The system delivers a 7.87 V/mm (200 mV/mil) incremental scale factor with +12.5%/-20% interchangeability error across the entire measurement range.
• Linear Operating Range: You achieve a 1.5 mm (60 mils) linear range starting at approximately 0.25 mm (10 mils) from the target surface.
• Output Characteristics: The probe produces approximately -1 to -13 Vdc across its linear range from 0.25 to 1.75 mm (10 to 70 mils) from the target.
• Recommended Gap Setting: We recommend setting the initial gap at 1.0 mm (40 mils) to center the probe optimally within its operating window.
• Frequency Response: The system provides 0 to 10 kHz frequency response with +0, -3 dB typical performance, supporting up to 305 meters of field wiring.
• Measurement Accuracy: You can expect less than ±0.06 mm (±2.3 mils) deviation from the best fit straight line for consistent, reliable measurements.
• Probe DC Resistance: The 1.0 meter probe length measures 4.2 ± 0.5 ohms from center conductor to outer conductor for excellent signal integrity.

Environmental and Mechanical Specifications

• Temperature Range: This 3300 NSv probe operates reliably in extreme environments from -52°C to +177°C (-62°F to +351°F) with identical storage temperature capabilities.
• Pressure Sealing: A Viton O-ring seals differential pressure between the probe tip and case, though standard units do not receive pressure testing before shipment.
• Material Construction: The probe tip utilizes Polyphenylene sulfide (PPS) while the case features AISI 304 stainless steel for outstanding corrosion resistance.
• Cable Assembly: The probe includes 1.0 meter of 75 Ω coaxial FEP-insulated cable with a miniature coaxial ClickLoc connector (Option -02).
• Bend Radius Protection: You can safely bend the cable to a 25.4 mm (1.0 in) minimum radius, even with the stainless steel armor installed.
• Installation Torque: Apply only finger tight pressure during probe installation, never exceeding 0.56 N•m (5 in•lb) of torque.

System Interconnect and Wiring Specifications

• Extension Cable Compatibility: Extension cables feature center conductor resistance of 0.220 Ω/m and shield resistance of 0.066 Ω/m for precise signal transmission.
• Capacitance Characteristics: Extension cables measure 69.9 pF/m (21.3 pF/ft) typical, maintaining signal fidelity over extended distances.
• Field Wiring Requirements: You can use 0.2 to 1.5 mm² (16 to 24 AWG) three-conductor shielded triad cable for monitor connections.
• Maximum Wiring Distance: The system supports up to 305 meters (1000 feet) between the 3300 NSv Proximitor Sensor and monitoring equipment.
• System Weight: The probe assembly weighs approximately 14 to 150 grams (0.5 to 5.3 ounces) depending on configuration and cable length.

Frequently Asked Questions

• Is this 330910-05-11-10-02-00 probe brand new and authentic Bently Nevada?
  Yes, we supply this 3300 NSv probe as a new and original item in factory-sealed packaging, ensuring complete authenticity and traceability.
• Do you have this specific 330910 configuration in stock?
  We maintain this exact 330910-05-11-10-02-00 configuration in our inventory, allowing immediate processing of your order without delays.
• How quickly will you ship this Bently Nevada proximity probe?
  We dispatch orders within five business days, using protective packaging to ensure safe transit of this precision instrument.
• Which shipping carriers do you use for probe deliveries?
  We ship through major international carriers including FedEx, UPS, and DHL, providing full tracking information for every order.
• What is your return policy for this 3300 NSv probe?
  You can return this item within 30 days of receipt, provided it remains in its original, unopened factory packaging.
• Can I use this probe with existing 3300 RAM extension cables?
  Absolutely, the 3300 NSv probe maintains complete mechanical and electrical interchangeability with previous 3300 RAM probe systems.
• What does the 50 mm unthreaded length mean for installation?
  The 50 mm unthreaded length provides a smooth section before threads begin, ideal for installations requiring the probe to pass through a clearance hole before engaging threads.
• Does the -02 connector option differ from -01?
  The -02 option specifies a miniature coaxial ClickLoc connector with standard cable, while -01 includes an additional connector protector for enhanced protection.
