330910-14-19-10-02-00 Bently Nevada 3300 NSv Proximity Probe

Pedidos al por mayor y envío rápido

Descuento instantáneo del 10% en EMI con tarjetas de crédito/débito Winter Banks y tarjetas de crédito

Envío rápido y fiable a todo el mundo – Listo para enviar desde stock
En stock (20 unidades), listo para ser enviado
  • Envío rápido
  • Política de devoluciones
  • Precio más bajo
  • Centro de ayuda 24/7

About the Product

330910-14-19-10-02-00 Bently Nevada 3300 NSv Proximity Probe - Precision Vibration Monitoring

Key Technical Specifications & Performance

  • Linear Range & Sensitivity: The probe provides a 1.5 mm (60 mils) linear range with a standard Incremental Scale Factor (ISF) of 7.87 V/mm (200 mV/mil). It operates effectively from 0.25 mm to 1.75 mm from the target.
  • Frequency Response & Accuracy: Enjoy a typical frequency response of 0 to 10 kHz (+0, -3 dB). The device ensures high accuracy with a Deviation from Straight Line (DSL) of less than ±0.06 mm (±2.3 mils).
  • Environmental Tolerance: Built for harsh conditions, it operates in temperatures from -52°C to +177°C (-62°F to +351°F). The probe case utilizes AISI 304 stainless steel with a PPS tip for excellent durability.
  • Electrical Characteristics: The system maintains a probe DC resistance of 4.2 ± 0.5 ohms. The extension cable features a center conductor resistance of 0.220 Ω/m and a shield resistance of 0.066 Ω/m.

Frequently Asked Questions (FAQ)

  • Is this 330910-14-19-10-02-00 probe new or used?
    We supply only brand new, original Bently Nevada 330910 units in factory packaging. We do not sell refurbished or used units.
  • What is the difference between this NSv probe and the old RAM probe?
    The 3300 NSv probe is mechanically and electrically interchangeable with the 3300 RAM but offers increased chemical resistance for use in process compressors.
  • What is the return policy for this Bently Nevada sensor?
    We accept returns within 30 days of delivery, provided the item is in its original, unopened condition.
  • Can I use this probe with long extension cables?
    Yes, you can use up to 305 meters (1000 feet) of field wiring between the Proximitor and the monitor, though high-frequency signal rolloff may occur at maximum length.
  • How should I torque the probe case to avoid damage?
    For the first three threads of the M10X1 case, do not exceed 22.6 N•m (200 in•lb). The recommended torque for full engagement is 11.3 N•m (100 in•lb).
