Allen-Bradley 20F11NC022JA0NNNNN | 415V 3-Phase Motor Drive

Allen-Bradley PowerFlex 753 Variable Frequency Drive

The Allen-Bradley 20F11NC022JA0NNNNN is a versatile variable frequency drive from the PowerFlex 753 series. This drive provides precise motor control for industrial automation applications. It delivers reliable performance with multiple control mode options.

Power & Electrical Specifications

• Product Model: Allen-Bradley 20F11NC022JA0NNNNN
• Power Rating: 11 kW Normal Duty / 7.5 kW Heavy Duty output
• Current Capacity: 22 Amperes continuous rated current
• Supply Voltage: 415 VAC nominal three-phase input

Control & Performance Features

• Control Modes: PID, V/Hz, and vector control capabilities
• DC Bus Voltage: Approximately 540 V DC nominal operation
• Braking System: Internal dynamic braking transistor included
• EMC Filtering: Built-in EMC filter with CM jumper installed

Physical Design & Cooling

• Cooling Method: Forced-air cooling system for thermal management
• Enclosure Type: Open chassis design (Frame 2) for flexible mounting
• Unit Weight: 20.00 lbs (9.07 kg) total packaged weight
• Input Design: AC input with DC precharge functionality

Functional Capabilities

• Embedded I/O: Standard onboard input/output functionality
• Diagnostic System: Built-in alarm and data monitoring features
• Human Interface: No local HMI module (blank panel configuration)
• System Integration: Compatible with standard industrial networks

Installation Guidelines

• Ensure adequate airflow for forced-air cooling system operation
• Verify power supply meets 415V AC three-phase nominal requirements
• Mount in appropriate location considering open chassis design
• Connect using recommended wiring practices for optimal performance

Shipping Information

• Package includes Allen-Bradley 20F11NC022JA0NNNNN drive unit
• Weight: 20.00 lbs (9.07 kg) with protective packaging materials
• International shipping via FedEx, UPS, or DHL available
• Standard order processing and delivery timelines apply

FAQ

• What is the power rating? 11 kW Normal Duty / 7.5 kW Heavy Duty
• What control modes are available? PID, V/Hz, and vector control
• What cooling method is used? Forced-air cooling system
• What is the input voltage? 415 VAC nominal three-phase supply
• Is EMC filtering included? Yes, built-in EMC filter with installed CM jumper
