330904-01-14-05-02-00 Bently Nevada Probe | 3300 NSv Sensor

Bently Nevada 3300 NSv Proximity Probe – 330904-01-14-05-02-00

Key Technical Specifications

• Brand: Bently Nevada
• Model: 330904-01-14-05-02-00
• Series: 3300 NSv Proximity Probe
• Probe Cable Length: 0.5 meter armored coaxial probe cable
• Linear Measurement Range: 1.5 mm displacement monitoring range
• Recommended Gap Setting: 1.0 mm distance between probe tip and target
• Frequency Response: 0 to 10 kHz vibration monitoring bandwidth
• Incremental Scale Factor: 7.87 V/mm (200 mV/mil)
• Linearity Deviation: Less than ±0.06 mm within the linear measurement range
• Probe Resistance: 4.0 ± 0.5 ohms for the 0.5 meter probe
• Operating Temperature: −52°C to +177°C industrial operating range
• Probe Tip Material: Polyphenylene sulfide (PPS)
• Probe Housing Material: AISI 304 stainless steel
• Minimum Target Diameter: 8.9 mm minimum, recommended 13 mm
• Minimum Cable Bend Radius: 25.4 mm

Environmental and Reliability Features

• The probe operates reliably within ambient temperatures from −52°C to +177°C.
• The Viton O-ring sealing structure protects internal components from pressure differences.
• The armored cable design improves durability in vibration monitoring environments.
• The probe maintains stable resistance and capacitance values during long-term industrial operation.
• The sensor supports hazardous area temperature classifications for industrial safety requirements.

FAQ

• Q: Is this proximity probe original?
  A: Yes, the product is brand new and original factory equipment.
• Q: Do you have this model available in stock?
  A: Yes, we currently keep stock for fast supply and industrial replacement needs.
• Q: When will you ship the order?
  A: We usually arrange shipment within five days after confirming the order.
• Q: Which logistics companies do you use?
  A: We commonly use DHL, FedEx, and UPS for international express delivery.
• Q: What displacement measurement range does the probe support?
  A: The probe provides a linear measurement range of 1.5 mm for accurate shaft displacement monitoring.
• Q: Can the probe operate in high temperature environments?
  A: Yes, the probe supports operating temperatures from −52°C to +177°C.
• Q: Do you support returns?
  A: Yes, we support returns within 30 days if the product remains unused and in original condition.
