330909-00-20-10-02-CN Bently Nevada 3300 NSv Armored Proximity Probe

Armored Probe Technical Specifications

  • Product Identification: Manufacturer: Bently Nevada. Model: 330909-00-20-10-02-CN (3300 NSv Proximity Probe with armor). This version includes country-specific approvals (-CN).
  • Mechanical Construction: It features a 3/8-24 UNF thread with stainless steel armor for added durability in abrasive environments. The overall case length is 2.0 inches.
  • Cable & Connector: Total probe length is 1.0 meter (39 inches). It uses a miniature coaxial ClickLoc connector (-02) with standard cable for a secure, tool-free connection.
  • Measurement Performance: Linear range spans 1.5 mm (60 mils) with a recommended gap of 1.0 mm (40 mils). It delivers an incremental scale factor (ISF) of 7.87 V/mm (200 mV/mil).
  • Accuracy Specifications: Deviation from best fit straight line (DSL) remains less than ±0.06 mm (±2.3 mils) over the full linear range.
  • Frequency Response: The system provides 0 to 10 kHz (+0, -3 dB) typical performance with up to 305 meters of field wiring.
  • Environmental Ratings: Operating temperature range is -52°C to +177°C (-62°F to +351°F). Probe tip uses Polyphenylene sulfide (PPS) with an AISI 304 stainless steel case.
  • Electrical Data: Probe DC resistance (center to outer conductor) measures 4.2 ± 0.5 ohms for this 1.0-meter configuration.
  • Installation Notes: Hand tighten only; maximum torque is 0.56 N•m (5 in•lb). The minimum bend radius is 25.4 mm (1.0 in) even with armor.

Frequently Asked Questions (FAQ)

  • What is the difference between the 330909 and 330908 models?
    The 330909 model includes stainless steel armor around the probe cable for protection, while the 330908 model does not include armor.
  • Is this armored probe compatible with my existing extension cable?
    Yes, this 3300 NSv Proximity Probe with armor is mechanically and electrically interchangeable with previous 3300 RAM extension cables.
  • What is the thread engagement limit for installation?
    For this 3/8-24 thread case, the maximum length of thread engagement is 0.563 inches. Follow the recommended torque specifications.
  • What field wiring length does this system support?
    You can use up to 305 meters (1000 feet) of three-conductor shielded triad cable between the proximitor and monitor.
  • How quickly can you ship this 330909-00-20-10-02-CN?
    We have this specific armored 3300 NSv model in stock and typically ship within 5 days via DHL, UPS, or FedEx.
