330910-00-11-10-02-05 3300 NSv Probe | Bently Nevada

Pesanan Massal & Pengiriman Cepat

Diskon Instan 10% untuk EMI dan Kartu Kredit/Debit Winter Banks

Pengiriman Cepat & Andal ke Seluruh Dunia – Siap Dikirim dari Stok
Tersedia (19 unit), siap dikirim
  • Pengiriman cepat
  • Kebijakan Pengembalian
  • Harga Terendah
  • Pusat Bantuan 24/7
  • Eladó:

    Bently Nevada

  • Típus:

    Probe

  • Tags Probe

A termékről

330910-00-11-10-02-05 Bently Nevada 3300 NSv Proximity Probe with Multiple Approvals

Key Technical Specifications & Performance Data

  • Linear Range & Sensitivity: The probe provides a 1.5 mm (60 mils) linear range with a standard Incremental Scale Factor (ISF) of 7.87 V/mm (200 mV/mil). The recommended operating gap is 1.0 mm (40 mils).
  • Frequency Response & Accuracy: Enjoy a typical frequency response of 0 to 10 kHz (+0, -3 dB). The 330910-00-11-10-02-05 ensures high accuracy with a Deviation from Straight Line (DSL) of less than ±0.06 mm (±2.3 mils).
  • Environmental Tolerance: Built for harsh conditions, it operates in temperatures from -52°C to +177°C (-62°F to +351°F). The probe case utilizes AISI 304 stainless steel with a PPS tip for excellent durability.
  • Electrical Characteristics: The system maintains a probe DC resistance of 4.2 ± 0.5 ohms. The extension cable features a center conductor resistance of 0.220 Ω/m and a shield resistance of 0.066 Ω/m.

Frequently Asked Questions (FAQ)

  • Is this 330910-00-11-10-02-05 probe new or used?
    We supply only brand new, original Bently Nevada 330910 units in factory packaging. We do not sell refurbished or used units.
  • What does the "-05" approval option mean?
    The -05 option indicates multiple agency approvals, making this variant suitable for installations requiring international safety certifications.
  • What is the return policy for this Bently Nevada sensor?
    We accept returns within 30 days of delivery, provided the item is in its original, unopened condition.
  • Can I use this probe with long extension cables?
    Yes, you can use up to 305 meters (1000 feet) of field wiring between the Proximitor and the monitor, though high-frequency signal rolloff may occur at maximum length.
  • How should I torque the probe case to avoid damage?
    For the first three threads of the M10X1 case, do not exceed 22.6 N•m (200 in•lb). The recommended torque for full engagement is 11.3 N•m (100 in•lb).
