GE Fanuc IC660EBA021 RTD Input Module | 6 Analog Inputs

GE Fanuc IC660EBA021 Technical Specifications

Product Identification

• Brand & Model: GE Fanuc IC660EBA021
• Product Type: Electronics Assembly for RTD Inputs
• I/O Type: Analog RTD temperature input module
• System Family: Genius I/O Platform

Technical Specifications

• Number of Inputs: 6 analog input circuits
• Input Grouping: 3 isolated groups of 2 inputs each
• Operating Voltage: 18 to 56 V DC
• Power Rating: 7 Watts
• Isolation: 300 Volts group isolation
• RTD Types: Nickel, Copper, Platinum
• Temperature Resolution: 0.1°C

Performance Specifications

• Accuracy: ±1.0°C (Platinum/Nickel), ±10.0°C (Copper)
• Update Time Options: 400 ms, 800 ms, or 1600 ms
• Measurement Range: 0 to 5000 Ohms
• Output Data Formats: Celsius, Fahrenheit, Ohms, or Count values
• Calibration: Pre-calibrated, no field calibration required
• Shelf Life: 1 year

Functional Features

• Mounting Method: Attaches to terminal base with top/bottom screws
• Protective Functions: Open wire, over/under range, short circuit, fault detection
• System Integration: Part of Genius I/O network
• Assembly Type: Electronics Block Assembly (EBA only)
• Temperature Sensing: Specifically designed for RTD temperature sensing
