Allen-Bradley 1756-L85EP ControlLogix 5580E Process Controller Key Advantages 40MB user memory for complex process applications Integrated Gigabit Ethernet port (10/100/1000 Mbps) Supports up to 300 EtherNet/IP devices Studio 5000 software compatible Technical Specifications Memory Capacity: 40MB User + 128K I/O I/O Capacity: 128,000 total...

Technical Specifications for 1756-M02AE Basic Information Manufacturer: Rockwell Automation Brand: Allen-Bradley Series: ControlLogix Part Number: 1756-M02AE Module Type: Servo Analog Encoder Module Key Features Axes per Module: Two (2) Axes per Controller: Thirty-Two (32) Input Type: Encoder input: Incremental AB quadrature with marker Discrete...

Allen-Bradley 1756-M16SE SERCOS Servo Module Key Features • Controls up to 16 servo axes per module • Dual-speed SERCOS interface (4/8 Mbps) • Supports position, velocity, and torque control modes • Fiber-optic communication for noise immunity Technical Specifications Data Rate 4 Mbps or 8...

Technical Specifications for 1756-N2 General Information ℹ️ Brand: Allen-Bradley Part Number: 1756-N2 Manufacturer: Rockwell Automation Series: ControlLogix Module Type: Slot Filler Module Function: Slot Filler Communications 📡 Communications: RS-232, RS-422, RS-485 No. of Slots Protected: Single Slot Power Specifications ⚡ Backplane Current (5 Volts):...

Allen-Bradley 1756-N2XT ControlLogix-XT Empty Slot Filler Card Model Identification 1756 - ControlLogix platform N2 - Slot filler series XT - Extreme temperature version Key Specifications Temperature Range: -25°C to +70°C operation Power Consumption: 6.2W (21.2 BTU/hour) Current Draw: 1.2A @ 5.1V DC Isolation: 50V...

Allen-Bradley 1756-OA16I 16-Channel Isolated AC Output Module Key Features 16 fully isolated AC output channels Wide voltage range: 74-265V AC High-density design saves panel space Individual channel isolation for safety Technical Specifications Output type: Isolated AC (47-63Hz) Current rating: 2A @ 30°C (1A @...

Allen-Bradley 1756-OA16IK Isolated AC Output Module ⚡ Power Specifications Voltage Range: 74-265V AC Current Capacity: 2A/point @30°C (1A @60°C) Total Module Current: 5A @30°C (4A @60°C) Power Dissipation: 5.5W max 🛡️ Isolation Features 16 individually isolated channels 50V continuous isolation Conformal coating protection 36-pin...

Allen-Bradley 1756-OA8 ControlLogix Digital AC Output Module – 8 Points, 74-265V AC Description The Allen-Bradley 1756-OA8 is a ControlLogix digital AC output module designed for industrial automation. It features 8 output points (grouped as 2x4) with an operating range of 74-265V AC (47-63 Hz)....

Allen-Bradley 1756-OA8E 8-Channel AC Output Module Key Advantages Electronically fused outputs for protection Individual channel diagnostics Compact single-slot design Wide voltage range operation Technical Specifications Output Channels: 8 (2 groups of 4) Voltage Range: 74-132V AC Current Capacity: 2A/point @ 60°C Max Module Current:...

Technical Specifications for 1756-OB16D Basic Information Brand: Allen-Bradley Part Number: 1756-OB16D Series: ControlLogix Module Type: Diagnostic DC Output Module Output Specifications Outputs: 16-Point Diagnostic Voltage: 24 Volts DC Source Operating Voltage Range: 19.2 - 30 Volts DC Power Consumption Backplane Current at 5 Volts:...

Allen-Bradley 1756-OB16DK ControlLogix Diagnostic DC Output Module – 16 Points, 24V DC Product Overview The Allen-Bradley 1756-OB16DK is a high-performance diagnostic DC output module for ControlLogix systems. With 16 diagnostic outputs (8 points per group), it delivers precise control for critical applications. Operating at...

Technical Specifications for 1756-OB16E Basic Information Manufacturer: Rockwell Automation Brand: Allen-Bradley Part Number: 1756-OB16E Module Type: Digital DC Output Module Series: ControlLogix Output Specifications No. of Outputs: Sixteen (16) Output Voltage Range: 10-31.2 VDC Nominal Output Voltage: 24VDC Maximum Output Current Rating (Point): 1...

Technical Specifications for 1756-OB16I Basic Information Brand: Allen-Bradley Part Number: 1756-OB16I Module Type: Isolated DC Output Module Outputs: 16-Point Individually Isolated Electrical Specifications Voltage: 12-24 Volts DC Sink-Source Operating Voltage Range: 10-30 Volts DC Output Delay Time (OFF to ON): 1 ms max Output...

Allen-Bradley 1756-OB16IEF ControlLogix Fast Isolated Output Module – 16 Points, 10-30V DC Product Overview The Allen-Bradley 1756-OB16IEF is a high-speed, isolated DC output module featuring ultra-fast 25μs response time and 16 individually isolated outputs. Designed for precision control applications, it supports Pulse Width Modulation...

Allen-Bradley 1756-OB16IEFK ControlLogix Isolated DC Output Module Core Features The 1756-OB16IEFK delivers 16 isolated DC outputs with 2A switching capacity per point. This industrial-grade module operates across a 10-30V DC range and features point-level electronic protection for reliable operation in demanding environments. Technical Specifications...

Allen-Bradley 1756-OB16IS Scheduled Isolated Output Module Key Features 16 isolated DC outputs (10-30V) 8 synchronized scheduled outputs 1ms ON / 2ms OFF switching speed CIPSync architecture compatible Individual channel isolation Technical Specifications Output type: Sinking/Sourcing DC Current rating: 2A @ 30°C (1A @ 60°C)...

1756-OB32 Technical Specifications 🔧 Manufacturer: Rockwell Automation 🏭 Brand: Allen-Bradley Outputs: 32-Point 📈 Module Type: DC Output Module Voltage: 12-24 Volts DC Source Operating Voltage Range: 10-31.2 Volts DC Output Delay Time, OFF to ON: 60 µs nom/1 ms max Current Draw @ 5.1V:...

Allen-Bradley 1756-OB8 ControlLogix 8-Channel Digital Output Module Core Features 8-channel 24VDC digital output High-speed switching (1ms ON / 2ms OFF) Removable terminal blocks (RTB) for easy wiring Compatible with all ControlLogix chassis Technical Specifications Output type: Sourcing (10-30VDC range) Current rating: 2A per point...

Allen-Bradley 1756-OB8I ControlLogix 8-Point Isolated DC Output Module Key Specifications • 8 individually isolated outputs • 12-24VDC nominal (10-30V range) • 2A current per point @ 60°C • 16A total module current • 0.5V max voltage drop @ 2A • 4A surge current (10ms...

1756-OBV8S ControlLogix 8-Channel Safety Output Module Safety-Critical Performance 8 dedicated safety outputs (10-30VDC) 0.5A per channel current rating Certified for safety applications Short-circuit and overcurrent protection Fast response time for emergency systems Technical Specifications Voltage Range: 10-30VDC Current per Point: 0.5A max Total Current:...
