Allen-Bradley 1756-L74 ControlLogix Processor Core Specifications • 16MB user memory • 0.98MB I/O memory • 1GB non-volatile memory (included) • Supports 128,000 digital I/O points • Handles 4,000 analog I/O points • 32 tasks with 100 programs each Key Features • Built-in USB 2.0...

Allen-Bradley 1756-RIO ControlLogix Remote I/O Module Core Specifications Network Role: Scanner or Adapter Max Racks: 32 physical racks (0-76 addressing) Data Types: Digital/Analog/Block Transfer Isolation: 50V continuous (RIO to backplane) Power Draw: 450mA @5.1V DC, 5mA @24V DC Thermal Dissipation: 8.5 BTU/hr Industrial Applications...

Allen-Bradley 1756-RM ControlLogix Redundancy Module - High Availability Solution CORE FUNCTIONALITY Enables seamless controller redundancy Supports 2x L6x controllers (L61-L63) or 1x L64 Manages up to 7 communication modules Single-mode LC fiber optic connection TECHNICAL SPECIFICATIONS Power requirements: • 1.2VDC @ 4mA • 5.1VDC...

Allen-Bradley 1756-RM2XT Extreme Environment Redundancy Module Core Features • Extreme temperature certified (T4 ATEX/IECEx/NA) • SIL 2 safety compliant for critical processes • 1300nm wavelength fiber optic synchronization • 4km maximum link distance • <1000Mbps data transmission rate Technical Specifications Electrical: 1.16A @5.1V DC,...

Technical Specifications for 1756-TBCH General Information ℹ️ Brand: Allen-Bradley Part Number: 1756-TBCH Series: ControlLogix Module Type: Terminal Block Connection Details 🔗 Clamp Type: Screw-Clamp Pins: 36-Pin Connection Screw Torque: 0.5 Nm (4.4 lb/in) Single Wire Connection: 0.33 to 2.1 mm² (22…14 AWG) Double Wire...

Allen-Bradley 1756-TBNH Removable Terminal Block Product Overview Model: 1756-TBNH Pins: 20-Pin Connection Wire Size: 20 AWG Electrical Specifications Backplane Current (5 Volts): 1,200 milliamps Backplane Current (24 Volts): 2.5 milliamps Power Dissipation (Max): 6.19 Watts Dimensions & Weight Weight:0.136KG Dimensions: 5.51 x 4.41 x...

📏 Technical Specifications 1756HP-TIME Time Synchronization Module Parameter Details Model 1756HP-TIME Type Time Synchronization Module Weight 0.53 lbs (approximately 0.24 kg) Power Requirements Compatible with ControlLogix system power inputs Operating Temperature -20°C to 60°C (-4°F to 140°F) Storage Temperature -40°C to 85°C (-40°F to...

Technical Specifications: Manufacturer: Allen-Bradley Model: 1761-L16BWB I/O Count: 16 points (8 inputs + 8 outputs) Input Type: 24V DC Digital Output Type: 6 relay contacts Input Voltage: 14 - 30V DC Relay Output Specifications: Inrush Current: 30A for 4 ms Operating Frequency: 47-63 Hz...

Allen-Bradley 1762-IA8 Digital Input Module Weight: 0.2 kg Input Power: 120 Volts AC Voltage Category: 100 to 120 Volts AC Number of Inputs: 8 Input Isolation Voltage: 500V AC Operating Temperature: -20°C to 55°C (-4°F to 131°F) Signal Types Supported: AC/DC compatible Highlighted Features...

Key Technical Specifications Manufacturer & Brand: Rockwell Automation (Allen-Bradley) Model: 1762-IF4 (Series: MicroLogix 1200; Product Family: MicroLogix) Input Channels: 4 differential (bipolar) channels, supporting both voltage and current signals Signal Ranges: - Voltage: Normal (-10.5V to +10.5V DC); Full-scale (-10V to +10V DC) -...

Specifications for 1762-IQ8 Product Overview Part Number: 1762-IQ8 Brand: Allen-Bradley Input Specifications No. of Inputs: Eight (8) channels No. of Groups: One (1) isolated group Channels per Group: Eight (8) Nominal Input Voltage: 24 VDC Input Voltage Range: 10-30 VDC Current Ratings ON-state Current,...

Allen-Bradley Controller Module - Part Number 1762-L40AWA Key Specifications: Weight: 0.75 kg Input Circuit Voltage: 120 Volts AC Number of Outputs: Sixteen (16) Output Characteristics: Output Type: Relay Relay Contact Rating: 24-125VDC; 120-240VAC Mechanical Operating Cycles: 20,000,000 Load Current Capability: 10A minimum Input and...

Ethernet Unmanaged Switches - 1783-US6T2F Total Ports: 8 Power Dissipation, Max: 5.927 W Manufacturer: Allen-Bradley Product Type: Stratix 2000 Ethernet Unmanaged Switches Weight: 0.45 kg SFP Slots: 2 Current Rating: 442.3 mA Power Supply Voltage: 24V (18...60V DC, 18...30V AC 50/60 Hz), Class 2/SELV...

1764-DAT Data Access Tool Manufacturer: Allen-Bradley Operating Temperature Range: 0 to 55 °C Power Specifications: Heat Dissipation: 1.75 Watts Bus Current Draw: 350 mA Weight: 0.2 kg Enhanced Features: Compact design ideal for space-constrained installations. Easy integration with existing Allen-Bradley systems. Safety Ratings: Designed...

Product Specifications Brand: Allen-Bradley Part Number: 1764-LRP Series: MicroLogix 1500 Product Family: MicroLogix Function: Processor Unit Product Type: MicroLogix Controller Memory: 14 KB Communication Ports: DH-485, Modbus, DF1, ACSII Supported Base Units: 1764-AWA; 1764-BWA; 1764-BXB Enclosure Type: IP20 Heat Dissipation: 1.9 Watts Power Supply:...

Bently Nevada 3500/40M Proximitor Monitor - Industrial Vibration Protection 176449-01 is a rugged monitoring module designed for critical machinery protection in demanding industrial environments. Manufactured in the U.S.A. to exacting standards. Core Specifications Part Number 176449-01 Model Series 3500/40M (Configuration: 01-02) Dimensions 241.3 ×...

Bently Nevada 3500/45 Position Monitor 176449-04 Product Overview This is a new original 3500/45 Position Monitor. The part number is 176449-04. It is a direct replacement for your old monitor. We ship fast with Fedex UPS or DHL. Your order comes with a full...

Allen-Bradley 1768-CNB Communication Interface Module Weight: 0.26 kg Power Consumption: 5.14 Watts Thermal Dissipation: 17.5 BTU/hr Backplane Current: 1 A at 5 Volts Isolation Voltage: 30 Volts ControlNet Speed: 5 Mbps Slot Configuration: 1 Slot Max Connections: 48 Connections Max Nodes: 99 Nodes Distinctive...

Product Specifications Brand: Allen-Bradley Part Number/Catalog No: 1768-L45 Product Line: CompactLogix Product Type: Controller Module Type: Processor Module Integrated Memory: 3MB Operating Temperature: 0° to +60°C (+32° to +140°F) Backplane Current: 2.0 Amps at 24 Volts Weight: 0.34 kg Maximum I/O Modules Supported: Up...

Product Specifications Part Number/Catalog No: 1768-M04SE Product Line: CompactLogix Module Type: 4 Axis Sercos Interface Module Bus Current Draw @ 5.2 VDC: 969 mA Module Location: Din Rail or Panel Mount Operating Temperature Range: -20°C to 60°C Connection Type: Sercos Dimensions: 100 mm x...
