100HP AC Drive Allen-Bradley 20F1AND125AA0NNNNN

Introducing the Allen-Bradley 20F1AND125AA0NNNNN PowerFlex 753 AC Drive

The Allen-Bradley 20F1AND125AA0NNNNN is a high-power AC drive from the PowerFlex 753 series, designed for demanding industrial motor control applications. This robust drive from Allen-Bradley delivers substantial power and advanced control features for heavy-duty automation systems. It provides reliable performance and flexible configuration options in large-scale manufacturing environments.

Core Technical Specifications

• Brand: Allen-Bradley
• Model: 20F1AND125AA0NNNNN
• Product Type: AC Drive
• Product Line: PowerFlex 753
• Power (Normal Duty): 100 HP / 75 kW
• Power (Heavy Duty): 75 HP
• Output Current: 125 A
• Input Voltage: 480 V AC
• DC Bus: 650 V DC
• Phase: 3-Phase
• Control Modes: V/Hz, Vector
• Cooling: Air cooled
• Enclosure: IP20 / IP00 rating
• Input Stage: AC + Precharge
• Filtering: EMC, jumper out configuration
• Braking: Internal transistor
• Operator Panel: Not included
• Slots: 3 expansion slots
• Unit Weight: 90.72 kg (200.00 lbs)

Performance and Control Features

• The Allen-Bradley 20F1AND125AA0NNNNN delivers 100 HP normal duty power
• High current capacity of 125 amps for demanding motor applications
• Multiple control modes including V/Hz and Vector control
• Internal braking transistor for effective motor deceleration
• Three expansion slots for enhanced functionality
• EMC filtering with jumper-out configuration for flexible setup

Installation and Application Details

• Open type design for control cabinet installation
• Heavy-duty 90.72 kg construction for industrial applications
• 480V AC 3-phase input with 650V DC bus capability
• AC input with precharge circuit for reliable operation
• IP20/IP00 enclosure rating for protected environments
• Three expansion slots for communication and I/O modules

Electrical and Environmental Specifications

• 480V AC 3-phase input voltage
• 650V DC bus voltage for power flexibility
• 125 amp continuous output current rating
• Air cooled thermal management system
• Dual power ratings for normal and heavy-duty operation
• Robust construction for continuous industrial use

Packaging and Delivery Information

• Includes one complete Allen-Bradley 20F1AND125AA0NNNNN AC drive
• Professional protective packaging ensures safe delivery
• Global shipping available via FedEx, UPS, or DHL carriers
• All necessary mounting hardware included

Frequently Asked Questions (FAQ)

• What is the horsepower rating?
  The 20F1AND125AA0NNNNN is rated 100 HP normal duty.
• What is the current capacity?
  125 amps continuous output current.
• What control modes are available?
  V/Hz and Vector control modes.
• What is the input voltage?
  480V AC 3-phase input.
• How many expansion slots does it have?
  Three expansion slots for additional modules.
• Is an operator panel included?
  No, operator panel is not included.
