1756-IM16I Digital AC Input Module Allen-Bradley

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (30 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1756-IM16I ControlLogix Isolated Input Module

Technical Specifications

  • Inputs: 16 Individually Isolated
  • Voltage Category: 240V AC, 50/60 Hz
  • Operating Voltage Range: 159-265V AC, 47-63 Hz
  • Input Voltage, Nom: 240V AC, 50/60 Hz
  • Current Draw @ 5.1V: 100 mA
  • Current Draw @ 24V: 3 mA
  • Weight: 0.32 kg (0.71 lb)

Performance Specifications

  • Total Backplane Power: 0.58 W
  • Power Dissipation (Max): 5.8 W @ 60°C (140°F)
  • Input Delay Time:
  • Off to On: 10 ms max + user-selectable filter time
  • On to Off: 8 ms max + user-selectable filter time
  • Inrush Current, Max: 250 mA
  • Isolation Voltage: 250V (continuous), inputs-to-backplane

Additional Features

  • Cyclic Update Time: 200 µs to 750 ms
  • Thermal Dissipation: 19.78 BTU/hr

Physical Characteristics

  • Removable Terminal Block: 1756-TBCH, 1756-TBS6H
  • Off-State Voltage, Max: 40 V
  • On-State Voltage Range: 159-265V AC
  • On-State Current, Min: 5 mA @ 159V AC
  • On-State Current, Max: 13 mA @ 265V AC
