1769-IT6 | 6 Channel Thermocouple/Mv Input Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (16 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Allen-Bradley

  • Type:

    Input Module

  • Tags Input module

About the Product

Allen-Bradley 1769-IT6 Thermocouple/mV Input Module

Key Features

  • 6-channel thermocouple/millivolt input module
  • Supports J, K, T, E, R, S, B, N, C thermocouples
  • Accepts ±50mV and ±10mV signals
  • Built-in cold junction compensation (CJC)
  • Auto-calibration on power-up

Technical Specifications

Input Resolution 16-bit (Delta-Sigma converter)
Temperature Ranges -270°C to +2315°C (depending on thermocouple type)
CJC Accuracy ±1.0°C (±1.8°F)
Power Consumption 100mA @ 5V DC, 40mA @ 24V DC
Dimensions 118 x 87 x 35mm (4.65 x 3.43 x 1.38in)

System Compatibility

  • CompactLogix controllers
  • MicroLogix 1500 systems
  • 1769-ADN DeviceNet adapter
  • 1769-AENTR Ethernet adapter

Installation Notes

  • DIN rail or panel mount options
  • Belden 8761 shielded cable recommended
  • Maintain 50mm clearance for ventilation
  • Keep 2 slots away from AC power supplies
  • Operating temp: 0°C to +60°C (32°F to +140°F)

Diagnostic Features

  • Open-circuit detection (7ms-2.1s response)
  • Short-circuit detection
  • Over/under-range monitoring
  • Selectable input filters (10Hz-1kHz)
  • Status indicators for each channel

Package Information

  • 1769-IT6 input module
  • Replacement terminal block (1769-RTBN18)
  • Mounting hardware
  • UPC: 10611320314424
  • Shipping weight: 2 lbs (0.9kg)
