1771-IGD Allen-Bradley - TTL Input Module

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1771-IGD TTL Input Module

Quick Facts

  • ✔ 16-channel TTL input module
  • ✔ Selectable positive/negative logic
  • ✔ Ultra-fast <1ms response time
  • ✔ Works with Series A/B chassis
  • ✔ Built-in status LEDs

Technical Highlights

Input Voltage Range 2.0-5.25VDC (ON), -0.2-0.8VDC (OFF)
Logic Options Positive or Negative (jumper selectable)
Backplane Current 130mA @ 5VDC
Isolation Rating 1500V AC RMS
Operating Temp 0°C to 60°C (32°F to 140°F)

Where It Works Best

• High-speed digital signal processing

• Laboratory test equipment interfaces

• Precision manufacturing systems

• Automated inspection machines

• Semiconductor handling equipment

What Makes It Special

• Dual logic mode operation

• 18 status indicators for easy monitoring

• Built-in surge protection

• Compatible with older PLC systems

• Rugged industrial design

Installation Checklist

① Requires 1771-WH wiring arm

② Use 14 AWG shielded cable

③ Set logic jumper before power-up

④ Allow 1.0 N·m terminal torque

⑤ Verify chassis compatibility

Package Contents

• 1771-IGD module

• Installation documentation

• 1-year warranty card
