184826-01 Bently Nevada 3500/94M VGA Module

Bently Nevada 3500/94M Main Module - Part Number 184826-01

Bently Nevada delivers reliable machinery protection. The 3500/94M Main Module (Part Number 184826-01) is a VGA display module for 3500 rack systems. This module shows real-time vibration data and system status. It operates from -20°C to +65°C. Use it for continuous monitoring in power plants, oil refineries, and factories. This unit comes new and original in factory packing with a 12-month warranty.

Product Overview

• Part Number: 184826-01
• Model: 3500/94M Main Module
• Manufacturer: Bently Nevada
• Condition: New and original in factory packing
• Warranty: 12 months factory warranty

Inputs and Outputs

• Power Consumption: 4.6 watts max, very efficient.
• High-Speed Network: Monitors status, data, and values.
• RS232 Port (I/O): Handles touch controller data.
• OK LED: Indicates proper module operation.
• TX/RX LED: Shows communication with other system modules.
• VGA Port (I/O): Outputs analog red, green, blue, and sync signals.
• Front Port: Provides 24 Vdc power out, VGA signal out, and touch commands in.

Environmental Limits

• Operating Temperature: -20°C to 65°C (-22°F to 149°F)
• Storage Temperature: -40°C to 85°C (-40°F to 185°F)
• Humidity: 95%, non-condensing

Compliance and Certifications

• FCC Part 15: This device may not cause harmful interference. This device must accept any interference received.
• EMC Standards: EN 61000-6-2, EN 61000-6-4, Directive 2014/30/EU
• Electrical Safety Standards: CSA C22.2 61010-1, UL EN 61010-1, Directive 2014/35/EU
• RoHS: Directive 2011/65/EU

Physical Characteristics

• Dimensions (H x W x D): 241.3 mm x 24.4 mm x 241.8 mm (9.5 in x 0.96 in x 9.52 in)
• Weight: 0.73 kg (1.6 lb)
• Rack Space: 1 full-height front slot

Firmware, Software, and Hardware Requirements

• Required Module: 3500/22 TDI (Transient Data Interface)
• 3500/94M Firmware: 4.06 Rev C or newer
• 3500/22 Firmware (TDI): Rev 1.71 or newer
• 3500/01 Software (Rack Config): Rev 5.6 or newer
• 3500/02 Software (Op Display): Rev 2.21 or newer
• 3500/03 Software (Data Acquisition): Rev 1.22 or newer

Package Contents

• 3500/94M Main Module (Part Number 184826-01)
• Factory packing with original box

Shipping Information

• Package weight: 0.73 kg
• We use FedEx, UPS, and DHL carriers
• Product origin: Made in USA

Frequently Asked Questions (FAQ)

• What is the part number for this module?
  The part number is 184826-01 for the 3500/94M Main Module.
• Does this module include a display screen?
  No. This is the main VGA display module only. You need a separate display.
• What firmware does the 3500/94M need?
  It needs firmware 4.06 Rev C or newer. The TDI requires Rev 1.71 or newer.
• What other module does this require?
  This module requires the 3500/22 TDI (Transient Data Interface) module to work properly.
• Can this module work below freezing?
  Yes. The 3500/94M operates at -20°C. Your display screen may need a heated enclosure below 0°C.
• Is this a genuine Bently Nevada part?
  Yes. This is a new and original Bently Nevada module in factory packing.

Expert Buying Guide

• Check your rack space: This module needs one full-height front slot in your 3500 rack.
• Verify TDI compatibility: You must have a 3500/22 TDI module installed. The 3500/94M will not work without it.
• Update your firmware first: Always check that your TDI has Rev 1.71 or newer before installing the 3500/94M.
• Power supply tip: Use a stable 24 Vdc power source for the connected display.
