2090-CPBM4DF-10AF07 Allen-Bradley Servo Cable | Kinetix 2090

Allen-Bradley 2090-CPBM4DF-10AF07 Servo Cable – High-Flex Feedback Cable for Kinetix Motion Systems

Technical Specifications

• Brand: Allen-Bradley
• Model: 2090-CPBM4DF-10AF07
• Category: Servo Cable / Feedback Cable
• Series: 2090 Servo Cable Series
• Cable Length: 10 meters (approx. 32.8 ft)
• Connector Type: Circular DIN, molded, factory-terminated
• Conductor Count: Multi-conductor with dedicated feedback and brake pairs
• Signal Type: Incremental encoder feedback, hall sensor, and brake control
• Frequency Response: Supports standard servo drive feedback frequencies up to 300 kHz
• Sensitivity: Low-capacitance design preserves weak encoder pulses over long runs
• Linearity: Stable signal transmission with minimal pulse distortion across the cable length
• Resolution: Compatible with high-resolution encoders used on Kinetix axes
• Temperature Range: -20 °C to +80 °C static, -10 °C to +70 °C dynamic
• Environmental Resistance: Oil-resistant, coolant-resistant, and flame-retardant jacket
• Noise Immunity: Overall foil and braided shield blocks EMI and RFI interference
• Bend Radius: Suitable for continuous flexing in cable carriers and moving gantries
• Voltage Rating: 300 V
• Manufacturer: Allen-Bradley / Rockwell Automation

Installation Guide

• Power down the drive and lock out the cabinet before you connect the cable.
• Align the keyed connector with the motor feedback port and push it straight in.
• Hand-tighten the coupling ring to seat the seal and prevent vibration loosening.
• Route the cable away from high-voltage motor power lines to reduce induced noise.
• Respect the minimum bend radius when you lay the cable in a moving carrier.
• Use strain relief clamps near both ends to protect the molded connectors.
• Check shield continuity and connector pinout before you apply drive power.
• Run a low-speed test move and verify feedback counts before full production.

Package List

• 1 × Allen-Bradley 2090-CPBM4DF-10AF07 servo cable, 10 m
• 1 × Protective connector cap set
• 1 × Anti-static protective bag
• 1 × Cable identification label

Shipping and Support

• Stock: We keep this item in stock for immediate order processing.
• Dispatch: We ship within 5 business days after we confirm your order.
• Couriers: FedEx, UPS, and DHL handle our international deliveries.
• Returns: You may return the item within 30 days of receipt.
• Condition: All units are brand new and original.

FAQ

• Q: What is the cable length of the 2090-CPBM4DF-10AF07?
  A: The cable measures 10 meters from connector to connector.
• Q: Which drives work with this servo cable?
  A: It pairs with Allen-Bradley Kinetix 6000 and Kinetix 6200 drive families.
• Q: Does this cable carry both feedback and brake signals?
  A: Yes, it combines encoder feedback and brake control in one cable.
• Q: What is the operating temperature range?
  A: It runs from -20 °C to +80 °C static and -10 °C to +70 °C dynamic.
• Q: How does the cable resist electrical noise?
  A: Foil and braided shields block EMI and RFI from nearby power lines.
• Q: Is this cable suitable for continuous flexing?
  A: Yes, the jacket and conductors handle repeated motion in cable carriers.
• Q: How fast do you ship this item?
  A: We dispatch in-stock orders within 5 business days via DHL, FedEx, or UPS.
• Q: Can I return the cable if it does not fit?
  A: You can request a return within 30 days of receiving the order.
