21000-16-10-15-092-03-02 Proximity Probe Housing Assembly

🚀 Industrial-Grade Proximity Monitoring Solution

Bently Nevada 21000 Series - Explosion-proof housing assembly with CSA/API certifications. Perfect for hazardous environments like oil refineries and power plants.

🔍 Key Features

• 8mm 3300 XL Probe with 1.0 m flexible cable
• 9.2" penetration depth | 1.5" standoff adapter
• Aluminum body + 304 stainless steel sleeve
• 3/4-14 NPT mounting thread (default)

📌 Model Details

Product Number: 21000-16-10-15-092-03-02
Suffix Breakdown:
• 16: 8mm Probe
• 10: 1.0m (39") Cable
• 15: 1.5" Adapter
• 092: 9.2" Penetration
• 03: NPT Fittings Kit

⚡ Performance Specs

• Range: 0-10 mm
• Accuracy: ±1% Full Scale
• Signal: Raw Voltage Output
• Temp Range: -50°C to +85°C
• Weight: 1.1 kg (without fittings)

✅ Certifications

CSA Approved for Explosion-Proof Areas
FCC Part 15 | RoHS Directive
API 670 Standard Compliant
Class 1 Div 1/2 & Class 2 Div 1/2 Certified

📦 Complete Package

• Probe housing assembly
• NPT plug & reducer
• Cable seal grip + 3 grommet sizes
• O-rings & installation docs

🏗️ Installation Made Easy

1. Screw housing into 3/4-14 NPT port
2. Set probe depth to 9.2"
3. Secure cables with seal grip
4. Connect to monitoring system

💡 Real-World Success

Chemical Plant: Prevented compressor failure by detecting abnormal vibrations
Mining Operation: Survived harsh conditions in CSA-certified explosion zones

🔒 Peace of Mind

12-month warranty | CSA-tested reliability | Email sales@nex-auto.com | Call +86 153 9242 9628
