21000-34-00-00-095-04-02 Bently Nevada 8mm Proximity Housing

21000-34-00-00-095-04-02 Bently Nevada Proximitor Sensor Housing

Technical Specifications

• Manufacturer & Model: Bently Nevada 21000-34-00-00-095-04-02 aluminum housing with stainless steel sleeve.
• Probe Compatibility: Accepts 3300 XL 8 mm probe with connector protector and hazardous area approvals (Suffix 34).
• Penetration Length: Provides extended 9.5-inch probe penetration (Suffix 095) for deep machinery casings.
• Mounting Thread: Equipped with standard 3/4-14 NPT mounting thread (Suffix -02) for secure installation.
• Environmental Rating: CSA certified as Type 4 enclosure, providing excellent protection against water and dust ingress.
• Physical Dimensions: Maximum (C) + (D) dimension of 32.9 inches (83.5 cm) with visible probe cable length of 1.0 meter.
• Weight: Approximately 1.1 kg (2.4 lb) without fittings, offering substantial protection without excessive weight.

Fitting Configuration

• Fitting Option 04: Includes one 3/4-14 NPT plug only for simplified conduit connections.
• Standoff Adapter: Configured with "No Adapter" option (Suffix 00) for direct mounting applications.
• Hazardous Location Rating: The 21000-34-00-00-095-04-02 carries explosion-proof certification for intrinsically safe installations.
• Material Construction: Aluminum body with 304 stainless steel sleeve ensures long-term durability in harsh environments.

Package Contents & Installation

• Included Components: Dome cover, threaded body, probe sleeve, O-rings, thread seal, and 3/4-14 NPT plug. (Probe not included - Suffix 00).
• Mounting Requirements: 3/4-14 NPT mounting thread provides compatibility with standard industrial fittings and machinery ports.
• Signal Integrity: Housing design minimizes electromagnetic interference for reliable proximity probe measurements.
• Shipping Options: We dispatch this new original Bently Nevada housing via FedEx, UPS, or DHL with tracking provided.

Frequently Asked Questions

• What is the penetration length difference between this model and the 039 version?
  This 21000-34-00-00-095-04-02 provides 9.5-inch penetration (Suffix 095), which is significantly longer than the 3.9-inch version for deeper machinery access.
• Does this housing come with cable sealing grips?
  No, this specific configuration uses Fitting Option 04, which includes only a 3/4-14 NPT plug. You will need to order sealing grips separately if required.
• Is this housing suitable for offshore or high-humidity environments?
  Yes, the combination of aluminum body and 304 stainless steel sleeve with CSA Type 4 rating makes it excellent for offshore, marine, and high-moisture applications.
• What is your current inventory status?
  We maintain stock of the 21000-34-00-00-095-04-02 as new factory-sealed units with 5-day dispatch availability.
• Can I return this item if my project requirements change?
  Yes, we offer 30-day returns on this housing provided it remains in original unopened factory packaging.
