21000-34-05-20-095-03-02 Bently Nevada 8mm Probe Housing

21000-34-05-20-095-03-02 Bently Nevada Proximitor Sensor Housing with Extended Penetration

Detailed Technical Specifications

• Manufacturer & Model: Bently Nevada 21000-34-05-20-095-03-02 aluminum housing with stainless steel reinforcement.
• Integrated Probe: Includes 3300 XL 8 mm probe with 0.5 meter cable length (Suffix 05) and connector protector for hazardous areas.
• Standoff Adapter: Features 2.0-inch standoff adapter (Suffix 20) for proper clearance from machine surfaces with insulation or uneven profiles.
• Extended Penetration: Provides 9.5-inch probe penetration (Suffix 095) for deep machinery casing applications.
• Mounting Thread: Equipped with standard 3/4-14 NPT mounting thread (Suffix -02) for secure industrial installation.
• Environmental Certification: CSA approved as Type 4 enclosure with explosion-proof rating for intrinsically safe applications.
• Compact Dimensions: Maximum (C) + (D) dimension of 13.5 inches (34.3 cm) with 0.5m probe cable for space-constrained installations.
• Weight: Approximately 1.1 kg (2.4 lb) without fittings, providing robust protection while maintaining manageable weight.

Complete Fitting Kit (Option 03)

• Comprehensive Fittings Package: Includes one 3/4-14 NPT plug and one 3/4-14 to 1/2-14 NPT reducer for versatile conduit connections.
• Multi-Size Cable Seal Grip: Comes with grommets accommodating three cable size ranges: 1/8 to 3/16, 1/4 to 5/16, and 5/16 to 3/8 inches.
• Hazardous Area Compatibility: The 21000-34-05-20-095-03-02 carries CSA certification for explosion-proof installations in hazardous environments.
• Material Construction: Aluminum body with 304 stainless steel sleeve ensures long-term durability in corrosive industrial environments.

Complete Package Contents & Installation

• Included Components: Dome cover, threaded body, 2.0-inch standoff adapter, probe sleeve, O-rings, thread seal, and complete fitting kit with cable grip.
• Probe Assembly: 3300 XL 8 mm reverse mount proximity probe with 0.5 meter cable and connector protector for selectable hazardous area approvals.
• Mounting Configuration: 3/4-14 NPT mounting thread provides compatibility with standard industrial machinery ports and fittings.
• Signal Integrity Protection: Housing design minimizes electromagnetic interference for accurate vibration and position measurements.
• Global Shipping Options: We dispatch this new original Bently Nevada housing via FedEx, UPS, or DHL with full tracking and insurance.

Frequently Asked Questions

• What makes this configuration unique for deep casing applications?
  This 21000-34-05-20-095-03-02 combines 9.5-inch penetration (Suffix 095) with a 2.0-inch standoff adapter, making it ideal for thick-walled machinery or insulated equipment.
• Why would I need both standoff adapter and long penetration?
  The 2.0-inch standoff provides clearance for conduit connections or insulation, while the 9.5-inch penetration reaches the target through thick casings—essential for large turbines or compressors.
• What is the advantage of the 0.5 meter probe cable?
  The shorter 0.5 meter cable (Suffix 05) reduces overall assembly length to 13.5 inches, making it suitable for installations with limited space near the machine.
• Is this housing suitable for offshore platform installations?
  Yes, the aluminum body with 304 stainless steel sleeve and CSA Type 4 rating provides excellent resistance to saltwater corrosion and harsh marine environments.
• Do you have this specific long-penetration model in stock?
  Yes, we maintain inventory of the 21000-34-05-20-095-03-02 as new factory-sealed units with 5-day dispatch availability.
• What is your return policy for this assembly?
  We offer 30-day returns on this complete housing and probe assembly provided it remains in original unopened factory packaging.
