31000-28-10-00-087-03-02 Bently Nevada Probe Housing 31000 Series

Bently Nevada 31000-28-10-00-087-03-02 Proximity Probe Housing

• Brand & Model: Bently Nevada 31000-28-10-00-087-03-02, part of the 31000 series probe housings.
• Probe Compatibility: Supports 3300 XL 8 mm probes with a 1.0 m (39 in) cable length.
• Configuration: No standoff adapter, 8.7 inches probe penetration, and 3/4-14 NPT mounting thread.
• Fittings Included: Two plugs, one 3/4-14 NPT fitting, one 3/4-14 to 1/2-14 NPT SST reducer, and a cable seal grip with three grommet sizes.

Core Technical Specifications

• Protection Ratings: CSA Type 4X certified and IP66 verified (SC115582-1 (e) 106). Also meets CENELEC EN50014 for electrostatic dissipation in hazardous areas.
• Housing Material: Glass-reinforced Polyphenylene Sulfide (PPS) thermoplastic with conductive fibers.
• Metal Components: Sleeve and chain use AISI 304 stainless steel; outer sleeve and screws use AISI 303 stainless steel.
• Sealing: Neoprene® O-ring between sleeve and housing, with an internal Viton® O-ring for probe seal.
• Temperature Range: Operates from -51°C to +105°C (-60°F to +221°F).
• Impact Strength: BASEEFA certified for two 4 Joule impacts at -39°C and 115°C. CSA verified 7 Joule impact resistance at room temperature.
• Load Capacity: Supports 912 N (205 lb) at 38 mm from the unsupported end with the cover fastened.
• Recommended Torque: Retaining nut torque is 29.4 N·m (260 in·lb).
• Weight: Typically 1.2 kg (2.6 lb).

Frequently Asked Questions (FAQ)

• Is this housing brand new and original?
  Yes, we supply only 100% genuine, new Bently Nevada 31000-28-10-00-087-03-02 units.
• Do you have stock available?
  Yes, we maintain ample stock of this model for immediate dispatch.
• What is the shipping timeline?
  We ship within 5 business days after order confirmation.
• Which carriers do you use?
  We ship via FedEx, UPS, and DHL for reliable worldwide delivery.
• Can I return the product?
  Yes, we support a 30-day return policy from the date of receipt.
• Is the housing rated for outdoor use?
  Yes, it carries IP66 and NEMA 4X ratings for harsh environments.
• Does the housing fit other probe types?
  This model is specifically designed for 3300 XL 8 mm probes.
• What is the temperature limit?
  The housing operates from -51°C to +105°C (-60°F to +221°F).
• What is the probe penetration for this model?
  This version provides 8.7 inches of probe penetration.
