3300 XL 8 mm Probe Bently Nevada 330101-00-20-05-02-05

3300 XL 8 mm Probe: High-Performance Vibration Monitoring Solution

Product Overview

The 330101-00-20-05-02-05 from Bently Nevada is an industrial-grade 8 mm proximity probe designed for precision vibration monitoring. Featuring a 3/8-24 UNF thread and 0.5-meter cable length, this probe delivers exceptional durability with Vitron® O-ring seals and 330 N (75 lbf) cable pull strength.

Key Specifications

• Dimensions: 2.0" case length | 11.4 oz/m weight
• Electrical: 7.45Ω ±0.50Ω DC resistance | 69.9 pF/m cable capacitance
• Performance: 7.87 V/mm ±5% scale factor | ±0.025 mm linearity deviation
• Environmental: Operates at -52°C to +177°C | Withstands 93% humidity for 56 days

Enhanced Features

• TipLoc® Technology: 40% stronger tip-body bond vs previous models
• FluidLock Option: Prevents fluid ingress with 10-bar pressure rating
• Material Superiority: PPS probe tip withstands 218°C | 304 SST casing

Certifications & Compliance

Approved for global use with CSA, ATEX, IECEx certifications. Meets IEC 68-2-3 humidity standards with <3% ASF variation.

Installation & Maintenance

• Field Wiring: Supports 16-24 AWG cables | 1,000 ft max length
• Gap Setting: Optimized at -9 Vdc (1.27 mm/50 mils)
• Pressure Warning: Avoid operation below -34°C (-30°F) to preserve seals

Why Choose This Probe?

8 mm probes offer 30% thicker encapsulation than standard models, with 2.5x vibration resistance in high-RPM applications. The ClickLoc connector enables 15-second installation versus traditional threaded designs.
