About the Product

Bently Nevada 330101-00-13-15-02-CN 3300 XL 8 mm Probe – Robust Precision for Vibration Monitoring

Key Technical Specifications

  • Brand & Model: Bently Nevada 330101-00-13-15-02-CN (3300 XL 8 mm Probe).
  • Thread Type: 3/8-24 UNF, without armor.
  • Unthreaded Length: 0.0 inches (standard).
  • Overall Case Length: 1.3 inches.
  • Total Length Option: 1.5 meters (4.9 feet) cable.
  • Connector Type: Miniature coaxial ClickLoc connector with standard cable.
  • Nominal DC Resistance (RPROBE): 7.73 ± 0.50 Ω for the 1.5 m system.
  • Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical.
  • Linear Range: 2 mm (80 mils). Range starts at 0.25 mm (10 mils) from target, extends 0.25 to 2.3 mm (10 to 90 mils).
  • Recommended Gap Setting: -9 Vdc (approx. 1.27 mm / 50 mils) for radial vibration.
  • Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±5% (standard 5 or 1 m system) over the 80 mil linear range.
  • Deviation from Best Fit Straight Line (DSL): Less than ±0.025 mm (±1 mil) for standard systems at 0°C to +45°C.
  • Probe Tip Material: Polyphenylene sulfide (PPS).
  • Probe Case Material: AISI 303 or 304 stainless steel (SST).
  • Weight: 323 g/m (11.4 oz per meter).
  • Standard Probe Temperature Range: -52°C to +177°C (-62°F to +350°F) operating and storage.
  • Extended Temperature Range Probe: Tip -52°C to +218°C; cable and connector -51°C to +260°C.
  • Pressure Seal: Viton® O-ring design seals differential pressure between tip and case.
  • Relative Humidity Stability: Less than 3% change in Average Scale Factor (ASF) after 56 days at 93% humidity (IEC 68-2-3).
  • Maximum Thread Engagement Length: 0.563 inches for 3/8-24 threads.
  • Recommended Torque (Standard forward mount): 11.2 N•m (100 in•lbf) full case; 7.5 N•m (66 in•lbf) for first three threads.
  • Field Wiring Recommendations: 0.2 to 1.5 mm² (16 to 24 AWG) three-conductor shielded triad cable, max 305 m (1000 ft) between sensor and monitor.

Frequently Asked Questions (FAQ)

  • Q: Is this probe brand new and original?
    A: Yes, we supply only brand new, original Bently Nevada products. The 330101-00-13-15-02-CN comes in factory packaging with full traceability.
  • Q: What is the linear range of this 3300 XL 8 mm probe?
    A: The linear range is 2 mm (80 mils), starting from 0.25 mm (10 mils) off the target up to 2.3 mm (90 mils), corresponding to -1 to -17 Vdc output.
  • Q: Can I use this probe in high-temperature applications?
    A: The standard version operates from -52°C to +177°C. If you require up to +218°C at the tip, please consider the extended temperature range version.
  • Q: What is the recommended torque for installation?
    A: For the standard forward-mounted probe, apply 11.2 N•m (100 in•lbf) for the full case. For first three threads, use 7.5 N•m (66 in•lbf) to avoid thread damage.
  • Q: Does the probe resist moisture and humidity?
    A: Yes, it passes IEC 68-2-3 humidity testing with less than 3% change in scale factor after 56 days at 93% relative humidity.
  • Q: What is the shipping lead time and carrier?
    A: We ship within 5 business days after order confirmation. We use DHL, FedEx, or UPS depending on your location, ensuring fast and reliable delivery.
  • Q: Do you have the 330101-00-13-15-02-CN in stock?
    A: Yes, we maintain ample stock of this Bently Nevada 3300 XL 8 mm probe. Contact us for immediate availability.
  • Q: What is your return policy?
    A: We support 30-day returns for unused items in original condition. Please contact our sales team for return authorization.
  • Q: Can I use this probe with a longer extension cable?
    A: Yes, the 3300 XL system allows extension cables up to 9 meters total length while maintaining specified performance. Use genuine Bently Nevada extension cables.
  • Q: Does the probe include the connector protection or armor?
    A: This specific model 330101-00-13-15-02-CN comes without armor and includes a miniature coaxial ClickLoc connector.
