330101-00-20-20-02-00 | Bently Nevada 3300 XL 8mm Probe 2m Cable

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Bently Nevada

  • Type:

    Probe

  • Tags Probe

About the Product

Bently Nevada 330101-00-20-20-02-00 3300 XL 8 mm Probe

Technical Specifications

  • Brand: Bently Nevada.
  • Model Number: 330101-00-20-20-02-00.
  • Nominal DC Resistance (RPROBE): 7.88 ± 0.50 Ω for 2.0 meter length.
  • Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical.
  • Linear Range: 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils).
  • Recommended Gap Setting (Radial Vibration): -9 Vdc (approx. 1.27 mm / 50 mils).
  • Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±5% for 1 or 5 meter system.
  • Deviation from Best Fit Straight Line (DSL): Less than ±0.025 mm (±1 mil) at 0°C to +45°C.
  • Probe Tip Material: Polyphenylene sulfide (PPS).
  • Probe Case Material: AISI 303 or 304 stainless steel (SST).
  • Weight: 323 g/m (11.4 oz).
  • Standard Probe Temperature Range: -52°C to +177°C (-62°F to +350°F).
  • Extended Temperature Range Probe: Tip up to +218°C (+425°F); cable up to +260°C (+500°F).
  • Relative Humidity Performance: Less than 3% change in ASF after 56 days at 93% humidity (IEC 68-2-3).

Frequently Asked Questions (FAQ)

  • How soon will you ship the probe?
    We ship within 5 days after order confirmation.
  • Which carriers do you use for delivery?
    We commonly use DHL, FedEx, and UPS for fast and reliable shipping.
  • Can I return the probe if needed?
    Yes, we support returns within 30 days from delivery.
  • What is the linear range of this 3300 XL 8 mm probe?
    The linear range is 2 mm (80 mils) from 0.25 mm to 2.3 mm from the target.
  • Does this probe work with extended temperature applications?
    Yes, the extended temperature version supports tips up to +218°C (+425°F).
  • What pull strength does the CableLoc design provide?
    It provides 330 N (75 lbf) pull strength for secure cable attachment.
