330101-00-66-20-02-00 Bently Nevada 3300 XL 8mm Probe

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (14 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Bently Nevada

  • Type:

    Probe

  • Tags Probe

About the Product

330101-00-66-20-02-00 | Bently Nevada 3300 XL 8 mm Probe

  • Brand & Model: Bently Nevada 330101-00-66-20-02-00 (3300 XL 8 mm Probe).
  • Thread Type: 3/8-24 UNF thread without armor.
  • Unthreaded Length Option: 00 = 0.0 inches.
  • Overall Case Length Option: 66 = 6.6 inches.
  • Total Length Option: 20 = 2.0 meters (6.6 feet).
  • Connector & Cable Type: 02 = Miniature coaxial ClickLoc connector with standard cable.
  • Nominal DC Resistance (RPROBE): 7.88 ± 0.50 Ω (center to outer conductor).
  • Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical.

Technical Specifications

  • Linear Range: 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils).
  • Recommended Gap for Radial Vibration: -9 Vdc (approx. 1.27 mm or 50 mils).
  • Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±5% for standard 5 or 1 meter system.
  • Deviation from Best Fit Straight Line (DSL): Less than ±0.025 mm (±1 mil) at 0°C to +45°C.
  • Probe Tip Material: Polyphenylene sulfide (PPS).
  • Probe Case Material: AISI 303 or 304 stainless steel (SST).
  • Weight: 323 g/m (11.4 oz per meter).
  • Standard Probe Temperature Range: -52°C to +177°C (-62°F to +350°F).
  • Extended Temperature Range (ETR): Probe tip -52°C to +218°C (-62°F to +425°F); cable -51°C to +260°C (-60°F to +500°F).
  • Pressure Seal: Viton® O-ring (not pressure tested before shipment).
  • Relative Humidity Performance: Less than 3% change in ASF after 56 days at 93% humidity (IEC 68-2-3).

Frequently Asked Questions (FAQ)

  • Q: Is this probe brand new and original?
    A: Yes. We supply only a brand new and original 330101-00-66-20-02-00 from Bently Nevada.
  • Q: Do you have this model in stock?
    A: Yes, we have it in stock and ready for immediate dispatch.
  • Q: What is your shipping time?
    A: We ship within 5 business days after order confirmation.
  • Q: Which carriers do you use?
    A: We use FedEx, UPS, and DHL for fast and reliable delivery.
  • Q: Can I return this probe?
    A: Yes. We offer a 30-day return policy from the delivery date.
  • Q: What happens if I need a pressure test for the seal?
    A: Contact our custom design department. We do not pressure test probes before shipment by default.
  • Q: Can I use this probe with a 9-meter extension cable?
    A: Yes. The standard 9-meter system has an ISF of 7.87 V/mm ±6.5% with DSL less than ±0.038 mm.
