330101-43-57-05-02-00 Bently Nevada | 3300 XL 8mm Probe

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (17 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Bently Nevada

  • Type:

    Probe

  • Tags Probe

About the Product

330101-43-57-05-02-00 – Bently Nevada 3300 XL 8 mm Probe

Technical Specifications

  • Brand & Model: Bently Nevada 330101-43-57-05-02-00 (3300 XL series).
  • Thread Type: 3/8-24 UNF, without armor.
  • Unthreaded Length: 4.3 inches (option 43).
  • Overall Case Length: 5.7 inches (option 57).
  • Total Length: 0.5 meter / 1.6 feet (option 05).
  • Connector: Miniature coaxial ClickLoc connector, standard cable (option 02).
  • Nominal DC Resistance (RPROBE): 7.45 ± 0.50 Ω (0.5m length).
  • Linear Range: 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils).
  • Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±5% (standard 1m system) from 0°C to +45°C.
  • Recommended Gap Setting (Radial Vibration): -9 Vdc [~1.27 mm / 50 mils].
  • Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical.
  • Probe Tip Material: Polyphenylene sulfide (PPS).
  • Probe Case Material: AISI 303 or 304 stainless steel (SST).
  • Probe Temperature Range (Standard): -52°C to +177°C (-62°F to +350°F).
  • Extended Temperature Range (Tip): -52°C to +218°C (-62°F to +425°F).
  • Probe Pressure Seal: Viton® O-ring design for differential pressure.
  • Relative Humidity Tolerance: Less than 3% change in ASF after 56 days at 93% humidity (IEC 68-2-3).
  • Field Wiring: 0.2 to 1.5 mm² (16-24 AWG), 3-conductor shielded triad, max 305 meters (1000 feet).
  • Weight: 323 g/m (11.4 oz).

Frequently Asked Questions (FAQ)

  • Do you have stock for 330101-43-57-05-02-00? - Yes, we keep 330101-43-57-05-02-00 in stock. Ready to ship.
  • What is the lead time? - We dispatch within 5 business days after order confirmation.
  • Which carriers do you use? - We ship via FedEx, UPS, and DHL for fast global delivery.
  • Can I return the probe? - Yes, we support 30-day returns. Conditions apply.
  • Does this probe work with 3300 XL extension cables? - Yes, it fully mates with standard 3300 XL extension cables (5 or 9 meter systems).
  • What is the maximum field wiring distance? - Up to 305 meters (1000 feet) between the Proximitor sensor and monitor.
