Bently Nevada 3300 XL 8 mm Proximity Probe
Model: 330103-06-13-10-02-00

• Manufacturer: Bently Nevada — 3300 XL series delivers precision eddy-current vibration monitoring for critical rotating machinery.
• Part number 330103-06-13-10-02-00 represents a fully configured 8 mm probe with M10 x 1 thread, unarmored, 60 mm unthreaded tip, 130 mm case length, and 1.0 m total cable.
• This configuration includes miniature coaxial ClickLoc connector with standard cable (option 02).
• Agency approval option 00 means this unit ships without formal certification — ideal for non-hazardous industrial installations.
• 330103-06-13-10-02-00 provides 2 mm linear range and operates from -52°C to +177°C.

Key technical specifications

• Linear range: 2 mm (80 mils), from 0.25 to 2.3 mm target gap.
• Output signal: -1 to -17 Vdc, recommended vibration gap -9 Vdc (1.27 mm).
• Probe DC resistance: 7.59 Ω ± 0.50 (for 1.0 m length).
• Frequency response: supports field wiring up to 305 m with minimal signal roll-off.
• Tip material: Polyphenylene sulfide (PPS); case material AISI 303/304 stainless steel.
• Temperature range: standard -52°C to +177°C; extended cable version available up to +260°C.
• Relative humidity: less than 3% ASF change after 56 days at 93% humidity.
• Pressure seal: Viton O-ring, differential pressure design.

Package contents

• One 330103-06-13-10-02-00 probe with integral standard cable and ClickLoc connector.
• Factory configuration: 60 mm unthreaded tip, 130 mm case thread, 1.0 m total length.
• Weight: 323 g per meter (11.4 oz per meter).
• Shipping: FedEx, UPS, or DHL express delivery.

Installation guidelines

• Use 3-conductor shielded triad field wire, 16 to 24 AWG (0.2 to 1.5 mm²).
• Maximum extension between probe and monitor: 305 meters (1000 feet).
• Thread engagement: maximum 15 mm for M10 x 1 case thread.
• For intrinsically safe applications, use approved barriers per drawing 141092.
• Non-incendive installations follow drawing 140979 for Class I, Zone 2.

Frequently asked questions

What makes 330103-06-13-10-02-00 different from other 3300 XL probes?
This model features a 60 mm unthreaded tip and 130 mm case length. It provides extended reach for deep mounting applications.

When should I choose the 60 mm unthreaded tip?
Select the 60 mm tip when the probe must extend significantly beyond the mounting surface to reach the target. It suits machines with thick casings.

What is the benefit of the 130 mm case length?
The 130 mm case allows deep thread engagement through bearing housings or insulation layers while maintaining probe stability.

Does this probe include hazardous area approvals?
No, option 00 means no certifications. Choose this version for general purpose areas where ATEX or CSA approvals are not required.

Can I use this probe with existing 3300 XL monitors?
Yes, the 3300 XL 8 mm series works with all 3300 XL Proximitor sensors without modification.
