330104-04-09-50-02-00 Bently Nevada Proximity Probe 5 Meter

330104-04-09-50-02-00 Bently Nevada 3300 XL 8 mm Proximity Probe – Precision Vibration Sensing

• Manufacturer: Bently Nevada – trusted name in machine protection.
• Model Number: 330104-04-09-50-02-00 (complete configuration).
• Series: 3300 XL 8 mm Proximity Probes, Metric version.
• Probe Type: 3300 XL 8 mm probe with M10 x 1 threads and armor.
• Unthreaded Length: 40 mm (option code 04).
• Overall Case Length: 90 mm (option code 09).
• Total Length: 5.0 meters (16.4 feet) – option code 50.
• Critical Note: This 5-meter probe only works with the 5 meter Proximitor sensor.
• Connector Type: Miniature coaxial ClickLoc connector with standard cable.
• Agency Approval: Not required (option code 00).

Key Technical Specifications

• Linear Range: 2 mm (80 mils). The linear zone starts at 0.25 mm from the target. It spans from 0.25 to 2.3 mm (10 to 90 mils). This equals -1 to -17 Vdc output.
• Recommended Gap (Radial Vibration): -9 Vdc. This matches approximately 1.27 mm (50 mils) gap distance.
• Probe DC Resistance (5.0m length): 8.73 ± 0.50 Ω (center conductor to outer conductor).
• Probe Tip Material: Polyphenylene sulfide (PPS) – robust and chemically stable.
• Probe Case Material: AISI 303 or 304 stainless steel (SST).
• Case Thread: M10 x 1. Maximum thread engagement reaches 15 mm.
• Probe Weight: 323 g per meter (11.4 oz per meter).

Temperature & Environmental Performance

• Standard Operating Temperature: -52°C to +177°C (-62°F to +350°F).
• Extended Temperature (Tip Only): -52°C to +218°C (-62°F to +425°F). The cable and connector handle -51°C to +260°C.
• Pressure Seal: Viton® O-ring seals differential pressure between tip and case. Bently Nevada does not pressure test each probe before shipping. Contact our custom department if you require a pressure seal test.
• Humidity Tolerance: Less than 3% change in Average Scale Factor (ASF) after 56 days at 93% relative humidity (IEC 68-2-3).
• Low Temperature Warning: Exposing the probe below –34°C (–30°F) may cause premature failure of the pressure seal.

Frequently Asked Questions (FAQ)

• Is this probe brand new and original? Yes, we supply 330104-04-09-50-02-00 as genuine Bently Nevada stock. No refurbished or counterfeit units.
• Do you have this model in stock? Yes, we keep the 3300 XL 8 mm probes in our warehouse inventory.
• What is the shipping lead time? We dispatch all orders within 5 working days after payment confirmation.
• Which couriers do you use for delivery? We ship worldwide via FedEx, UPS, and DHL. You can choose your preferred carrier.
• Can I return this probe if it doesn't fit my application? Yes, we support 30-day returns for unused items in original packaging. Please contact us first for return authorization.
• Why does this probe require a 5 meter Proximitor sensor? Bently Nevada designs 5-meter probes with specific resistance values. They only work correctly with the matching 5 meter Proximitor sensor.
• Is the pressure seal tested before shipment? Bently Nevada does not pressure test each probe individually. Contact our custom design department if your application requires a pressure seal test.
• What happens if I use this probe below -34°C? Temperatures below –34°C (–30°F) may cause the Viton® O-ring seal to fail prematurely. Stay within -52°C to +177°C for standard operation.
