330104-19-25-10-11-05 Bently Nevada 3300 XL 8mm Probe ATEX

3300 XL 8 mm Proximity Probe – Model 330104-19-25-10-11-05 by Bently Nevada

• Brand: Bently Nevada – industry leader in machinery protection systems.
• Product model: 330104-19-25-10-11-05 – 3300 XL 8 mm probe with armor.
• Unthreaded length: 190 mm (option 19) for extended mounting depth.
• Overall case length: 250 mm (option 25) fits deeper metric housings.
• Total length: 1.0 meter (3.3 feet) – option 10 cable assembly.
• Connector type: Miniature coaxial ClickLoc connector with connector protector and FluidLoc cable (option 11).
• Agency approval: CSA, ATEX, IECEx Approvals (option 05) – suitable for hazardous locations.

Key technical specifications

• Probe tip material: Polyphenylene sulfide (PPS) offers outstanding chemical resistance.
• Probe case material: AISI 303 or 304 stainless steel (SST).
• Linear range: 2 mm (80 mils) from 0.25 mm to 2.3 mm (10 to 90 mils).
• Output voltage range: Approximately –1 to –17 Vdc across the full linear range.
• Recommended gap for radial vibration: –9 Vdc, equal to 1.27 mm (50 mils).
• Nominal DC resistance (RPROBE): 7.59 ± 0.50 Ω for the 1.0 meter length.
• Maximum probe case torque: 33.9 N•m (300 in•lbf); recommended torque 11.2 N•m (100 in•lbf).
• Probe thread size: M10x1, maximum thread engagement 15 mm.
• Weight: 323 g/m (11.4 oz).

Temperature & environmental endurance

• Standard probe operating & storage temperature: –52°C to +177°C (–62°F to +350°F).
• Extended temperature range probe tip: –52°C to +218°C (–62°F to +425°F).
• Extended range cable & connector: –51°C to +260°C (–60°F to +500°F).
• Do not expose the probe below –34°C (–30°F) to prevent pressure seal failure.
• Relative humidity performance: Less than 3% change in Average Scale Factor (ASF) at 93% humidity for 56 days (IEC 68-2-3).
• Pressure seal design: Viton® O‑ring seals differential pressure between tip and case.
• Note: Bently Nevada does not pressure test each probe before shipping. Contact our custom design team for seal testing requirements.

Frequently Asked Questions (FAQ)

• Is this 330104-19-25-10-11-05 a genuine new original part?
  Yes, we supply only brand new, original Bently Nevada inventory. No refurbished or counterfeit units.
• Do you have this 3300 XL 8 mm probe in stock?
  Yes, we keep the 330104-19-25-10-11-05 model in stock for immediate shipment.
• What approvals does this probe carry?
  This model includes CSA, ATEX, and IECEx certifications – ideal for hazardous area installations.
• What is the FluidLoc cable?
  FluidLoc cable provides enhanced resistance to fluids and oils, improving reliability in wet environments.
• What is the typical shipping time after placing an order?
  We ship within 5 days. Express carriers like FedEx, UPS or DHL deliver in 2–5 business days.
• Can I return this probe if it does not fit my application?
  We support a 30‑day return policy from delivery date. The product must be unused and in original packaging.
• What is the linear measurement range of this probe?
  The linear range is 2 mm (80 mils), starting at 0.25 mm and ending at 2.3 mm from the target.
• What is the difference between standard and extended temperature probe?
  Standard probe works from –52°C to +177°C; extended tip reaches +218°C and cable up to +260°C.
• Does the probe require external pressure testing before installation?
  Bently Nevada does not pre‑test each probe. If your application demands seal testing, contact our custom design team.
