330130-070-13-CN - Bently Nevada - Extension Cable

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
Only 10 units left
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Bently Nevada 330130-070-13-CN Extension Cable

Key Features

  • Product Type: Extension Cable
  • Manufacturer: Bently Nevada
  • Product No.: 330130-070-13-CN
  • Cable Length: 7.0 meters (22.9 ft)
  • Cable Type: Armored FluidLoc cable with connector protector
  • Approvals: CN (Country Specific)
  • Made in: U.S.A.

Electrical Specifications

Proximitor Sensor Input Accepts one 3300-series 5 mm, 8 mm or 3300 XL 8 mm proximity probe & extension cable
Power Requirement -17.5 Vdc to -26 Vdc at 12 mA max (without barriers)
-23 Vdc to -26 Vdc (with barriers)
Supply Sensitivity < 2 mV output change per volt input change
Output Resistance 50 Ω
Extension Cable Capacitance 69.9 pF/m (21.3 pF/ft), typical

Nominal Cable DC Resistance

Length (m) RCORE (Ω) RJACKET (Ω)
7.0 1.54 ± 0.23 0.46 ± 0.09

Mechanical Specifications

  • Standard Extension Cable: 34 g/m (0.4 oz/ft), 0.204 kg
  • Armored Extension Cable: 103 g/m (1.5 oz/ft), 0.618 kg
  • Connectors: Corrosion-resistant, gold-plated ClickLoc™
  • Cable Options: FluidLoc design prevents oil leakage

Environmental

  • Operating Temperature: -51°C to +177°C (-60°F to +350°F)
  • Relative Humidity: ≤3% change in ASF at 93% humidity (IEC standard 68 2 3, up to 56 days)
  • Pressure Seal: Viton® O-ring (probes not pressure tested before shipment)

Additional Notes

  • Each extension cable is supplied with silicone tape (recommended only for non-oil applications).
  • Patented TipLoc® molding ensures secure bonding of probe tip and body.
  • CableLoc® design provides 330 N (75 lbf) pull strength.
  • Maximum field wiring length: 305 m (1000 ft) between Proximitor and monitor.
