330173-00-04-20-02-05 Bently Nevada Proximity Probes

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (16 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Bently Nevada

  • Type:

    5mm Probe

  • Tags 5mm probe

About the Product

330173-00-04-20-02-05 Bently Nevada 3300 5mm Probe

  • Manufacturer & Series: Bently Nevada, 3300 series.
  • Model Number: 330173-00-04-20-02-05 (with multiple agency approvals).
  • Probe Length: 2.0 meters (6.6 feet).
  • Overall Case Length: 40 mm (option 04).
  • Unthreaded Length: 0 mm (option 00).
  • Thread Size: M8 x 1 (without armor).
  • Connector Type: Miniature coaxial ClickLoc connector (standard cable).
  • Tip Material: Polyphenylene sulfide (PPS).
  • Case Material: AISI 304 stainless steel (SST).
  • Weight: 0.323 Kg.
  • Temperature Range: Operates from -35°C to +177°C (-31°F to +351°F).
  • DC Resistance (Center to Outer): 7.88 ± 0.50 Ω (for 2.0m length).
  • Power Supply: Requires -17.5 Vdc to -26 Vdc at 12 mA max.
  • Sensitivity: Less than 2 mV change per volt change in input voltage.
  • Output Resistance: 50 Ω.
  • Recommended Torque: 5.1 N·m (45 in·lb) for probe case; 0.565 N·m max for connector.
  • Minimum Cable Bend Radius: 25.4 mm (1.0 inch).

Frequently Asked Questions (FAQ)

  • Is this probe compatible with the 3300 XL series? Yes, it works with Bently Nevada 3300 XL systems that accept a 5mm probe with M8 thread.
  • Can I use this probe in high-temperature areas? Yes, the probe supports temperatures from -35°C to +177°C.
  • What is the overall case length of this probe? The overall case length is 40 mm (option 04).
  • What is the thread engagement limit for this probe? The maximum thread engagement length is 12 mm for M8x1 threads.
  • Do you have this item in stock? Yes, we keep 330173-00-04-20-02-05 in stock and ready to ship.
  • What is the total length of the probe alone? The total length option is 2.0 meters (6.6 feet).
  • What is the DC resistance value for this probe? The resistance from center to outer conductor is 7.88 ± 0.50 Ω.
  • Does this probe come with armor? No, this version is without armor.
  • What is the recommended torque for installation? 5.1 N·m (45 in·lb) for the probe case; maximum 0.565 N·m for the connector.
