330173-00-08-05-02-05 Bently Nevada - 5mm Probe

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (16 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7
  • Vendor:

    Bently Nevada

  • Type:

    5mm Probe

  • Tags 5mm probe

About the Product

Bently Nevada 330173-00-08-05-02-05 5mm Proximity Probe

Key Technical Specifications

  • Manufacturer: Bently Nevada (part of Baker Hughes).
  • Model Number: 330173-00-08-05-02-05 (3300 series, 5mm probe).
  • Unthreaded Length: 0 mm (Option 00).
  • Overall Case Length: 80 mm (Option 08).
  • Total Cable Length: 0.5 meter (1.6 feet, Option 05).
  • Connector Type: Miniature coaxial ClickLoc with standard cable (Option 02).
  • Agency Approval: Multiple approvals (Option 05).
  • Probe Tip Material: Polyphenylene sulfide (PPS).
  • Probe Case Material: AISI 304 stainless steel (SST).
  • Probe DC Resistance: 7.45 ± 0.50 Ω (center to outer conductor).
  • Output Resistance: 50 Ω.
  • Power Supply: Requires -17.5 Vdc to -26 Vdc (12 mA max).

Environmental & Mechanical Ratings

  • Probe Temperature Range: -35°C to +177°C (-31°F to +351°F).
  • Thread Engagement Limit: Maximum 12 mm for M8x1 threads.
  • Tensile Strength: 222 N (50 lbf) for probe case to lead.
  • Recommended Torque: 5.1 N·m (45 in·lb), maximum 7.3 N·m (65 in·lb).
  • Minimum Cable Bend Radius: 25.4 mm (1.0 inch).
  • Probe Cable: 75 Ω triaxial, FEP insulated (0.5, 1, 2, 5, or 9 meter lengths).

Performance Characteristics

  • Supply Sensitivity: Less than 2 mV change per volt change in input voltage.
  • 60 Hz Magnetic Field Rejection (5m system):
    Gap 10 mil: Probe 0.0004 mV/mil/G; Gap 50 mil: Probe 0.0014; Gap 90 mil: Probe 0.0045.
  • Temperature Classification (EPL Ga/Gc): T1 to T5 (ambient -55°C to +232°C down to +40°C).
  • EPL Dc Classifications: T280°C to T90°C with corresponding ambient ranges.
  • System Accuracy: Specified with AISI 4140 steel target at 1.27 mm (50 mils) gap.

Frequently Asked Questions (FAQ)

  • Q: Is the Bently Nevada 330173-00-08-05-02-05 a genuine product?
    A: Yes, we supply only brand new, original Bently Nevada probes.
  • Q: What is the total length of this probe system?
    A: The total length option is 0.5 meter (1.6 feet), as shown in the model number.
  • Q: Can I use this probe with an extension cable?
    A: Yes, it uses a triaxial FEP cable and connects via standard ClickLoc connectors.
  • Q: What is the maximum operating temperature for this probe?
    A: The probe operates from -35°C up to +177°C (-31°F to +351°F).
  • Q: How should I torque the probe case?
    A: Apply 5.1 N·m (45 in·lb) recommended torque, never exceed 7.3 N·m.
  • Q: Do you have this probe in stock?
    A: Yes, we maintain stock and can ship within 5 days via FedEx, UPS, or DHL.
  • Q: What is the thread size for installation?
    A: It has an M8 x 1 thread with a maximum engagement of 12 mm.
  • Q: Can I return this item if it doesn't fit my application?
    A: Yes, we accept returns within 30 days for any reason.
