330702-00-30-10-02-05 3300 XL Proximity Probe Bently Nevada

Bently Nevada 330702-00-30-10-02-05 3300 XL 11 mm Proximity Probe

• Manufacturer: Bently Nevada (Made in U.S.A).
• Product Number: 330702-00-30-10-02-05.
• Probe Type: 3300 XL 11 mm proximity probe with armor and 1/2-20 UNF thread.
• Unthreaded Length: 0.0 inches (Option 00).
• Overall Case Length: 3.0 inches (Option 30).
• Total Length: 1.0 meter (3.3 feet, Option 10).
• Connector & Cable: Miniature coaxial ClickLoc connector with standard cable (Option 02).
• Agency Approval: Multiple Approvals (Option 05).

Technical Specifications

• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST) with gold-plated brass components.
• Cable Specification: 75 Ω triaxial, FEP insulated, available in 1, 5, or 9 meters.
• Operating Temperature: -51°C to +177°C (-60°F to +351°F).
• Storage Temperature: -52°C to +177°C (-62°F to +351°F).
• Probe Pressure Seal: Viton O-ring design; optional pressure test available upon request.
• DC Resistance (RPROBE): 5.9 ± 0.5 ohms for 1.0 m length.
• Minimum Bend Radius: 25.4 mm (1.0 inch) with or without SST armor.
• 60 Hz Magnetic Field Immunity: See detailed gap-based output table below.

60 Hz Magnetic Field Effects (5 meter system)

• At 0.5 mm (20 mil) gap: Proximitor Sensor 0.006, Probe 0.001, Ext. Cable 0.001 (mV pp/gauss).
• At 2.5 mm (100 mil) gap: Proximitor Sensor 0.033, Probe 0.009, Ext. Cable 0.005.
• At 4.6 mm (180 mil) gap: Proximitor Sensor 0.033, Probe 0.027, Ext. Cable 0.007.

Mechanical & Installation Data

• Case Thread: 1/2-20 UNF.
• Max Thread Engagement: 0.750 inch.
• Rated Torque (Max): 45.2 N•m (400 in•lb).
• Recommended Torque: 15.0 N•m (133 in•lb).
• Connector Torque: Finger tight recommended; max 0.565 N•m (5 in•lb).
• Alternative Threads: M16x1.5 (max 24 mm) and M14x1.5 (max 21 mm).
• Avoid exposing the probe below -34°C (30°F) to protect the pressure seal.
• This 3300 XL probe is not pressure tested before shipping; contact our design team for testing.

Temperature Classifications (EPL Ga, Gc, Dc)

• T1: -55°C to +232°C (EPL Ga/Gc).
• T2: -55°C to +177°C.
• T3: -55°C to +120°C.
• T4: -55°C to +80°C.
• T5: -55°C to +40°C.
• For EPL Dc: T280°C @ Ta (-55°C to +232°C), T225°C @ Ta (-55°C to +177°C), T170°C @ Ta (-55°C to +120°C), T130°C @ Ta (-55°C to +80°C), T105°C @ Ta (-55°C to +100°C), T90°C @ Ta (-55°C to +40°C).

Package & Logistics

• Shipping Weight: 0.17 Kg.
• Packaging: Includes the probe with ClickLoc connector and standard cable.
• Shipping Carriers: FedEx, UPS, DHL.
• We stock 330702-00-30-10-02-05 as brand new, original units.
• Orders dispatch within 5 business days.
• We accept returns within 30 days of delivery.

Frequently Asked Questions (FAQ)

• Is the probe pressure tested before shipment?
  No, we do not pressure test standard probes. We offer custom testing upon request.
• What is the total length of this model?
  The 330702-00-30-10-02-05 has a total length of 1.0 meter (3.3 feet).
• What approvals does this probe carry?
  This model has Multiple Approvals (Option 05), suitable for various hazardous areas.
• Can I use this probe in high-temperature environments?
  Yes, it operates from -51°C to +177°C, but avoid temperatures below -34°C.
• What connector does this probe have?
  It features a miniature coaxial ClickLoc connector with standard cable.
• Do you have these in stock?
  Yes, we keep 330702-00-30-10-02-05 in stock for immediate shipment.
