330702-00-30-90-01-00 11mm Probe 3300 XL Bently Nevada

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (14 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Bently Nevada 3300 XL 11 mm Probe Assembly - Model 330702-00-30-90-01-00

Key Technical Specifications

  • Manufacturer: Bently Nevada (Made in U.S.A).
  • Model Number: 330702-00-30-90-01-00.
  • Probe Type: 3300 XL 11 mm probe with armor, 1/2-20 UNF thread.
  • Unthreaded Length: 0 inches (option 00).
  • Overall Case Length: 3.0 inches (option 30).
  • Total Length: 9.0 meters (29.5 feet, option 90).
  • Connector & Cable: Miniature coaxial ClickLoc connector with protector, standard cable (option 01).
  • Agency Approval: Not required (option 00).
  • Probe Tip Material: Polyphenylene sulfide (PPS).
  • Probe Case Material: AISI 304 stainless steel (SST).
  • Cable Specification: 75 Ω triaxial, FEP insulated, total lengths 1, 5, or 9 meters.
  • Operating Temperature: -51°C to +177°C (-60°F to +351°F).
  • Storage Temperature: -51°C to +177°C (-60°F to +351°F).
  • Pressure Seal: Viton O-ring design, differential pressure sealing.
  • Shipping Weight: 0.17 Kg.
  • DC Resistance (RPROBE): 8.5 ± 1.1 ohms (for 9.0 m length).
  • Case Thread: 1/2-20 UNF, max thread engagement 0.750 in.
  • Maximum Case Torque: 45.2 N•m (400 in•lb).
  • Recommended Case Torque: 15.2 N•m (133 in•lb).
  • Connector Torque: Finger tight recommended; max 0.565 N•m (5 in•lb).
  • Minimum Bend Radius: 25.4 mm (1.0 in) with or without armor.
  • 60 Hz Magnetic Field Effect (5m system): Output voltage in mil pp/gauss at 0.5 mm gap: Proximitor 0.006, Probe 0.001, Ext. Cable 0.001.
  • Temperature Classifications (EPL Ga/Gc): T1 (-55°C to +232°C), T2 (-55°C to +177°C), T3 (-55°C to +120°C), T4 (-55°C to +80°C), T5 (-55°C to +40°C).

Frequently Asked Questions (FAQ)

  • Q: Is this probe a genuine Bently Nevada product?
    A: Yes, it is 100% brand new and original, directly from Bently Nevada.
  • Q: What is the total length of the 330702-00-30-90-01-00 probe?
    A: The total length is 9.0 meters (29.5 feet), as indicated by the option code 90.
  • Q: Can I use this probe in high-temperature environments?
    A: Yes, it operates from -51°C to +177°C (-60°F to +351°F). Check the temperature classification for your specific EPL.
  • Q: What is the recommended torque for the probe case?
    A: The recommended torque is 15.2 N•m (133 in•lb), and the maximum is 45.2 N•m (400 in•lb).
  • Q: How quickly will you ship my order?
    A: We ship within 5 business days after order confirmation.
  • Q: What shipping carriers do you use?
    A: We use FedEx, UPS, and DHL for fast and reliable delivery.
  • Q: Do you offer returns?
    A: Yes, we support returns within 30 days of receipt.
  • Q: Is the probe pressure tested before shipment?
    A: Standard probes are not pressure tested; contact our custom department if you require a test.
