330702-00-30-90-11-00 Bently Nevada 3300 XL 11mm Probe

Bently Nevada 330702-00-30-90-11-00 3300 XL 11 mm Proximity Probe

• Manufacturer & Series: Bently Nevada, 3300 XL Series.
• Model Number: 330702-00-30-90-11-00 (Probe, 1/2-20 UNF thread, with armor).
• Unthreaded Length: 0.0 inches (Option 00).
• Overall Case Length: 3.0 inches (Option 30).
• Total Cable Length: 9.0 meters / 29.5 feet (Option 90).
• Connector Type: Miniature coaxial ClickLoc connector with connector protector, FluidLoc cable (Option 11).
• Agency Approval: Not required (Option 00).
• Probe Tip Material: Polyphenylene sulfide (PPS).
• Probe Case Material: AISI 304 stainless steel (SST).
• Cable Specification: 75 Ω triaxial, FEP insulated cable.
• DC Resistance (RPROBE): 8.5 ± 1.1 ohms (center to outer conductor).
• Case Thread: 1/2-20 UNF; maximum thread engagement 0.750 inch.
• Recommended Torque: 15.2 N•m (133 in•lb); max 45.2 N•m (400 in•lb).
• Connector Torque: Finger tight recommended; max 0.565 N•m (5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 inch) with or without armor.
• Operating & Storage Temperature: -51 °C to +177 °C (-60 °F to +351 °F).
• Shipping Weight: 0.17 Kg.

Installation & Handling Guidelines

• Use the 1/2-20 UNF thread for mounting; do not exceed 0.750 inch of thread engagement.
• Apply recommended torque of 15.2 N•m (133 in•lb) to avoid damage.
• Keep the connector-to-connector joint finger tight, max 0.565 N•m.
• Maintain a minimum bend radius of 25.4 mm for the probe cable.
• Avoid exposing the probe below -34 °C (30 °F) to protect the pressure seal.
• This 9.0 meter probe works with standard Proximitor sensors; verify compatibility.

Environmental & Pressure Specifications

• The Viton* O-ring seals differential pressure between tip and case.
• Operating and storage range: -51 °C to +177 °C (-60 °F to +351 °F).
• Temperature classification (EPL Ga/Gc): T1 to T5 as per ambient conditions.
• For EPL Dc: T280°C @ -55°C to 232°C, and other ratings provided.
• Probes are not pressure tested before shipment; contact custom design if needed.

Package Contents

• 1 x Bently Nevada 330702-00-30-90-11-00 3300 XL 11 mm Proximity Probe.
• Integrated 9.0 meter triaxial FEP FluidLoc cable with miniature ClickLoc connector and protector.
• Standard mounting hardware and documentation (if applicable).

Shipping & Support

• We ship via FedEx, UPS, or DHL within 5 business days.
• All items are brand new and original with full factory specification.
• We offer a 30-day return policy for unused items in original condition.
• Stock is available for immediate order; contact us for bulk inquiries.

Frequently Asked Questions (FAQ)

• Is the probe brand new and original?
  Yes, we supply only 100% new and original Bently Nevada probes.
• What is the exact model for this 9m probe?
  The model is 330702-00-30-90-11-00, a 3300 XL 11 mm probe with 9.0 meter FluidLoc cable.
• What is the FluidLoc cable option?
  Option 11 includes a miniature coaxial ClickLoc connector with connector protector and FluidLoc cable for improved fluid resistance.
• What is the recommended mounting torque?
  Bently Nevada recommends 15.2 N•m (133 in•lb) for the 1/2-20 UNF thread.
• What is the temperature limit for this probe?
  Operating range is -51 °C to +177 °C (-60 °F to +351 °F) per specification.
• Do you have stock and how fast do you ship?
  Yes, we have stock. We ship within 5 business days via FedEx, UPS, or DHL.
• What is your return policy?
  We accept returns within 30 days for unused items in original packaging.
