About the Product

Bently Nevada 3300 XL 11 mm Proximity Probe for Industrial Monitoring

Key Technical Specifications

  • Brand and Model: Bently Nevada 3300 XL 11 mm Proximity Probe (P/N: 330707-00-20-10-01-05).
  • Probe Thread and Length: 5/8-18 UNF thread with a 2.0-inch overall case length and 0.0-inch unthreaded length.
  • Total Cable Length: 1.0 meter (3.3 feet) standard cable with a miniature coaxial ClickLoc connector.
  • Construction Materials: Polyphenylene sulfide (PPS) probe tip and AISI 304 stainless steel case.
  • Cable Type: 75 Ω triaxial cable with fluoroethylene propylene (FEP) insulation.
  • Operating Temperature: -51°C to +177°C (-60°F to +351°F).
  • Probe DC Resistance: 5.9 ± 0.5 ohms between the center and outer conductors.
  • Agency Approval: Holds multiple agency approvals (Option 05).

Installation and Handling Guidelines

  • Recommended Torque: Tighten the probe case to 15.2 N•m (133 in•lb). The maximum rated torque is 45.2 N•m (400 in•lb).
  • Connector Torque: Tighten the connector only to finger tight. Do not exceed 0.565 N•m (5 in•lb).
  • Bend Radius: Maintain a minimum bend radius of 25.4 mm (1.0 inch) for the probe cable.
  • Thread Engagement: The maximum length of thread engagement for this 5/8-18 case is 0.938 inches.
  • Pressure Seal: A Viton O-ring provides the pressure seal, though the probe is not pressure tested before shipping.

Package Contents

  • 1 x Bently Nevada 3300 XL 11 mm Proximity Probe (Model 330707-00-20-10-01-05).
  • Probe is shipped as a complete assembly with the standard cable and ClickLoc connector.

Frequently Asked Questions (FAQ)

  • Q: What is the condition of this probe?
    A: The Bently Nevada 3300 XL 11 mm Proximity Probe is brand new and original.
  • Q: Do you have the 330707-00-20-10-01-05 in stock?
    A: Yes, we have this model in stock and ready to ship.
  • Q: What is the shipping method and delivery time?
    A: We ship via FedEx, UPS, or DHL. Orders will be dispatched within 5 days of purchase.
  • Q: What is the operating temperature range of this sensor?
    A: It operates reliably in temperatures from -51°C to +177°C.
  • Q: What is the return policy?
    A: We offer a 30-day return policy for this product.
  • Q: What is the probe tip made of?
    A: The probe tip is made from durable Polyphenylene sulfide (PPS).
