330707-00-20-90-11-05 11mm Probe Bently Nevada 9m FluidLoc Cable

Bently Nevada 3300 XL 11 mm Proximity Probe with 9-Meter FluidLoc Cable

Key Technical Specifications

• Manufacturer and Model: Bently Nevada 3300 XL 11 mm Proximity Probe (P/N: 330707-00-20-90-11-05).
• Probe Thread and Length: 5/8-18 UNF thread with a 2.0-inch overall case length and zero unthreaded length.
• Total Cable Length: 9.0 meters (29.5 feet) with FluidLoc cable and miniature coaxial ClickLoc connector.
• Construction Materials: Polyphenylene sulfide (PPS) probe tip and AISI 304 stainless steel case.
• Cable Type: 75 Ω triaxial cable with fluoroethylene propylene (FEP) insulation.
• Operating Temperature: -51°C to +177°C (-60°F to +351°F). Avoid prolonged exposure below -34°C to protect the pressure seal.
• Probe DC Resistance: 8.5 ± 1.1 ohms between the center and outer conductors for the 9-meter length.
• Agency Approval: Holds multiple agency approvals (Option 05).

Installation and Handling Guidelines

• Recommended Torque: Tighten the probe case to 15.2 N•m (133 in•lb). The maximum rated torque is 45.2 N•m (400 in•lb).
• Connector Torque: Tighten the connector only to finger tight. Do not exceed 0.565 N•m (5 in•lb).
• Bend Radius: Maintain a minimum bend radius of 25.4 mm (1.0 inch) for the probe cable.
• Thread Engagement: The maximum length of thread engagement for this 5/8-18 case is 0.938 inches.
• Pressure Seal: A Viton O-ring provides the pressure seal, though the probe is not pressure tested before shipping.

Package Contents

• 1 x Bently Nevada 3300 XL 11 mm Proximity Probe (Model 330707-00-20-90-11-05).
• Probe assembly with 9-meter FluidLoc cable and ClickLoc connector pre-installed.

Frequently Asked Questions (FAQ)

• Q: What is the condition of this probe?
  A: The Bently Nevada 3300 XL 11 mm Proximity Probe is brand new and original.
• Q: Is the 330707-00-20-90-11-05 in stock?
  A: Yes, we have this model in stock and ready for immediate shipment.
• Q: What are the shipping options and delivery time?
  A: We ship via FedEx, UPS, or DHL. Orders dispatch within 5 business days.
• Q: What is the DC resistance for the 9-meter cable?
  A: The resistance is 8.5 ± 1.1 ohms between the center and outer conductors.
• Q: What is the temperature limit for this sensor?
  A: It operates from -51°C to +177°C, but do not expose it below -34°C for extended periods.
• Q: What is your return policy?
  A: We offer a 30-day return policy on this product.
