330707-00-62-50-01-00 Bently Nevada 3300 XL 11mm Proximity Probes

Bently Nevada 3300 XL 11 mm Proximity Probe (Model: 330707-00-62-50-01-00)

Key Technical Specifications

• Brand & Model: Bently Nevada 3300 XL 11 mm Proximity Probe, 330707-00-62-50-01-00.
• Probe Thread: 1/2-20 UNF thread for standard mounting.
• Overall Case Length: 6.2 inches for extended reach.
• Total Cable Length: 5.0 meters (16.4 feet) with stainless steel armor for cable protection.
• Connector Type: Miniature coaxial ClickLoc connector with connector protector and standard cable.
• Agency Approval: Option 00 indicates no specific approval required for this configuration.
• Probe Tip Material: Durable Polyphenylene sulfide (PPS) for precise sensing.
• Probe Case Material: Corrosion-resistant AISI 304 stainless steel (SST).
• Cable Specification: 75 Ω triaxial cable with fluoroethylene propylene (FEP) insulation.
• Temperature Range: Operates from -51°C to +177°C (-60°F to +351°F).
• Probe DC Resistance (5m): 7.2 ± 0.8 ohms from center to outer conductor.
• Shipping Weight: Lightweight at 0.17 Kg.

Installation and Torque Guidelines

• Case Thread & Engagement: 1/2-20 UNF with a maximum engagement length of 0.750 inches.
• Case Torque: Apply the recommended torque of 15.0 N•m (133 in•lb), not exceeding 45.2 N•m (400 in•lb).
• Connector Torque: Tighten finger-tight only, with a maximum of 0.565 N•m (5 in•lb).
• Minimum Bend Radius: Maintain a minimum bend radius of 25.4 mm (1.0 inch) for the probe cable.
• Pressure Seal: The probe seals differential pressure with a Viton O-ring; it is not pressure tested before shipment.
• Important Note: This 5.0-meter probe is specifically designed for use with the 5-meter Proximitor Sensor only.

Temperature Classification (Probe Only)

• For EPL Ga and Gc: T1 (-55°C to +232°C), T2 (-55°C to +177°C), T3 (-55°C to +120°C), T4 (-55°C to +80°C), T5 (-55°C to +40°C).
• For EPL Dc: T280°C (-55°C to +232°C), T225°C (-55°C to +177°C), T170°C (-55°C to +120°C), T130°C (-55°C to +80°C), T105°C (-55°C to +100°C), T90°C (-55°C to +40°C).

Package Contents

• 1 x Bently Nevada 3300 XL 11 mm Proximity Probe (Model: 330707-00-62-50-01-00).
• Pre-attached 5.0 meter armored cable with ClickLoc connector and connector protector.
• Standard packaging and documentation as per manufacturer.

Shipping & Returns

• Shipping: We ship worldwide via FedEx, UPS, or DHL for fast and reliable delivery.
• Stock Status: This item is in stock and ready to ship.
• Dispatch Time: Orders dispatch within 5 business days.
• Returns: We accept returns within 30 days of purchase.

Frequently Asked Questions (FAQ)

• Is this probe brand new and original?
  Yes, the 330707-00-62-50-01-00 is a brand new, original Bently Nevada unit.
• What does the armored cable option provide?
  The "50" total length option includes stainless steel armor, which offers extra protection against mechanical damage in harsh environments.
• Why must I use this with a 5-meter Proximitor Sensor?
  This probe's 5.0-meter length is electrically matched to the 5-meter Proximitor Sensor for accurate readings.
• What is the DC resistance for this 5-meter probe?
  For the 5.0-meter length, the resistance from the center to the outer conductor is 7.2 ± 0.8 ohms.
• What approvals does this probe carry?
  The "00" option means this configuration does not require specific agency approvals for standard industrial use.
