330708-00-25-90-02-00 11 mm Proximity Probe Bently Nevada

Bently Nevada 3300 XL 11 mm Proximity Probe – 330708-00-25-90-02-00 Technical Overview

• 330708-00-25-90-02-00 features a Polyphenylene sulfide (PPS) probe tip. The tip material resists high temperatures and chemicals.
• Probe case uses AISI 304 stainless steel (SST). This construction provides excellent mechanical strength and corrosion resistance.
• Unthreaded Length Option 00 = 0.0 in. Overall Case Length Option 25 = 2.5 in. Total Length Option 90 = 9.0 meters (29.5 feet).
• Connector and Cable-Type Option 02 = Miniature coaxial ClickLoc connector with standard cable.
• Agency Approval Option 00 = Not required. This probe fits applications without special agency certifications.

Key Technical Specifications

• Brand: Bently Nevada. Model: 330708-00-25-90-02-00. Series: 3300 XL 11 mm Proximity Probes.
• Probe Cable: 75 Ω triaxial with fluoroethylene propylene (FEP) insulation. Total probe lengths available: 1, 5 or 9 meters.
• Probe DC Resistance: For 9.0 meter length, resistance from center conductor to outer conductor equals 8.5 ± 1.1 ohms.
• Operating and Storage Temperature: -51°C to +177°C (-60°F to +351°F). Exposing the probe below -34°C (30°F) may cause premature seal failure.
• Probe Pressure Design: Seals differential pressure between tip and case using a Viton O-ring. Bently Nevada does not pressure test before shipment.
• Probe Case Thread: 5/8-18 UNF. Maximum thread engagement length equals 0.938 inch. Also supports M16x1.5 (24 mm) and M14x1.5 (21 mm).
• Maximum Rated Torque: 45.2 N•m (400 in•lb). Recommended Torque: 15.2 N•m (133 in•lb) for 5/8-18 and 1/2-20 cases.
• Connector-to-Connector Torque: Finger tight recommended. Maximum torque equals 0.565 N•m (5 in•lb).
• Minimum Bend Radius: 25.4 mm (1.0 inch) with or without stainless steel armor.
• Shipping Weight: 0.17 kg. Lightweight design simplifies handling and installation.

Frequently Asked Questions (FAQ)

• Is the 330708-00-25-90-02-00 probe new and original?
  Yes, we supply only brand new and original Bently Nevada parts. No refurbished or counterfeit items.
• Do you have this proximity probe in stock?
  Yes, we maintain stock for 3300 XL 11 mm Proximity Probes. The 330708-00-25-90-02-00 is available for immediate shipping.
• How long does delivery take?
  We ship within 5 days after purchase. Then FedEx, UPS or DHL delivers typically in 3–7 business days.
• Can I return the probe if it does not fit my application?
  Absolutely. Our 30-day return policy accepts unused items in original condition. Contact sales for RMA.
• What is the exact probe tip material?
  Polyphenylene sulfide (PPS) tip provides excellent durability and chemical resistance for industrial use.
• Does the probe withstand high pressure?
  The probe uses a Viton O-ring for differential pressure sealing. Bently Nevada does not pre-test pressure seals. Contact custom design for testing needs.
• What cable length options exist for 3300 XL probes?
  Standard total probe lengths: 1 meter, 5 meters or 9 meters. The 330708-00-25-90-02-00 has 9.0 meter length.
• Is the probe compatible with 75 ohm extension cables?
  Yes, the probe uses a 75 Ω triaxial cable. Use only Bently Nevada approved cables for best signal integrity.
• What is the maximum thread engagement for 5/8-18 UNF?
  Maximum length equals 0.938 inch. Do not exceed this value to avoid damaging the case or thread.
• What thread options does this probe support besides 5/8-18?
  The probe case also works with M16x1.5 (24 mm engagement) and M14x1.5 (21 mm engagement).
