330709-00-05-10-12-05 Bently Nevada 3300 XL 11mm Probe

Bently Nevada 330709-00-05-10-12-05 3300 XL 11 mm Proximity Probe

• Brand & Model: Bently Nevada 330709-00-05-10-12-05 belongs to the 3300 XL 11 mm Proximity Probe family.
• Probe DC Resistance: The center conductor to outer conductor resistance (RPROBE) is 5.9 ± 0.5 ohms for the 1.0 metre length.
• Target & Shaft Specifications: Recommended minimum flat target diameter equals 30.5 mm (1.2 in). The shaft diameter must be at least 152 mm (6.0 in) to avoid cross-talk.
• Material Construction: The probe tip uses Polyphenylene sulfide (PPS). The case is AISI 304 stainless steel (SST) for durability.
• Cable & Connector: 75 Ω triaxial FEP insulated cable comes in 1, 5, or 9 metre total lengths. The ClickLoc connector ensures a secure fit.

Technical Specifications

• Thread & Engagement: M16 x 1.5 probe case thread. Maximum thread engagement length is 24 mm.
• Torque Values: Recommended probe case torque is 63.3 N•m (560 in•lb). Connector-to-connector torque should be finger tight up to 0.565 N•m (5 in•lb).
• Temperature Range: Operating and storage range spans -52°C to +177°C (-62°F to +351°F). Note that exposure below -34°C (30°F) may damage the pressure seal.
• Minimum Bend Radius: The probe cable allows a 25.4 mm (1.0 in) minimum bend radius, with or without SST armor.
• Agency Approval: Option 05 provides multiple approvals for worldwide use.

Installation Guidelines

• Use the specified torque values to avoid damaging the probe case or connector.
• Ensure the target surface is flat and meets the minimum diameter requirement.
• Maintain the minimum shaft diameter to prevent cross-talk interference.
• Keep the cable bend radius above 25.4 mm to preserve signal integrity.
• Apply only finger tight torque on the connector, not exceeding 0.565 N•m.

Package Contents

• Bently Nevada 330709-00-05-10-12-05 3300 XL 11 mm proximity probe (1 unit)
• Integrated 1.0 metre triaxial FEP cable with ClickLoc connector
• FluidLoc cable assembly for harsh environments
• Installation and safety instruction sheet

Shipping & Returns

• We ship via FedEx, UPS, or DHL from our warehouse.
• All orders dispatch within 5 business days after order confirmation.
• We support a 30-day return policy for unused items in original packaging.
• Inventory is available; we stock genuine new units ready for shipment.

Frequently Asked Questions (FAQ)

• Is this probe brand new and original? Yes, we supply 100% genuine Bently Nevada 330709-00-05-10-12-05 probes directly from the manufacturer.
• What is the exact DC resistance of this probe? The RPROBE measures 5.9 ± 0.5 ohms for the 1.0 metre length.
• Can I use this probe on a 100 mm shaft? No, the recommended minimum shaft diameter is 152 mm (6.0 in) to avoid cross-talk.
• What temperature range can this probe withstand? It operates from -52°C to +177°C. Avoid temperatures below -34°C to protect the pressure seal.
• How long does shipping take? We dispatch within 5 days via FedEx, UPS, or DHL. Delivery time depends on your location.
• Do you have these in stock? Yes, we maintain inventory of the 330709-00-05-10-12-05 for immediate shipment.
• What is the return policy? We accept returns within 30 days for unused items in original condition.
