330709-000-040-10-11-00 Bently Nevada 3300 XL Probe

330709-000-040-10-11-00 3300 XL 11 mm Proximity Probe

• Manufacturer & Series: Bently Nevada, 3300 XL 11 mm Proximity Probes. The model 330709-000-040-10-11-00 offers a 1.0 meter total length with a Miniature coaxial ClickLoc connector.
• Probe Configuration: This unit has an M16 x 1.5 thread without armor. The unthreaded length is 0 mm, and the overall case length measures 40 mm.
• Electrical Characteristics: The probe DC resistance from the center conductor to the outer conductor (RPROBE) is 5.9 ± 0.5 ohms for the 1.0-meter length.
• Cross-talk Limitation: For flat surfaces, the recommended minimum target diameter is 30.5 mm (1.2 in). The recommended minimum shaft diameter is 152 mm (6.0 in).
• Materials & Cable: The probe tip uses Polyphenylene sulfide (PPS). The case is AISI 304 stainless steel (SST). The cable is a 75 Ω triaxial, FEP-insulated type, available in 1, 5, or 9-meter lengths.
• Mechanical Torque Specifications: For the M16x1.5 case, the maximum rated torque is 63.3 N•m (560 in•lb), while the recommended torque is 21.1 N•m (187 in•lb). The connector-to-connector torque should be finger tight, with a maximum of 0.565 N•m (5 in•lb).
• Temperature Range: The operating and storage temperature spans from -52°C to +177°C (-62°F to +351°F). Exposing the probe below -34°C (30°F) may cause premature failure of the pressure seal.
• Temperature Classification (EPL Ga/Gc): T1 (-55°C to +232°C), T2 (-55°C to +177°C), T3 (-55°C to +120°C), T4 (-55°C to +80°C), T5 (-55°C to +40°C).
• Temperature Classification (EPL Dc): T280°C @ Ta (-55°C to +232°C), T225°C @ Ta (-55°C to +177°C), T170°C @ Ta (-55°C to +120°C), T130°C @ Ta (-55°C to +80°C), T105°C @ Ta (-55°C to +100°C), T90°C @ Ta (-55°C to +40°C).
• Installation & Handling: The probe case thread is M16x1.5 with a maximum thread engagement of 24 mm. The minimum bend radius (with or without armor) is 25.4 mm (1.0 in).

Package Contents

• 1 x 330709-000-040-10-11-00 3300 XL 11 mm Proximity Probe (1.0 meter, ClickLoc connector).
• Connector protector and FluidLoc cable as specified.
• Installation guide (basic instructions).

Shipping & Returns

• We ship all orders within 5 business days from our warehouse.
• We use reliable carriers like FedEx, UPS, and DHL for fast delivery.
• We offer a 30-day return policy for unused items in original packaging.
• All products are brand new and original from the manufacturer.
• We maintain ample stock to fulfill your order promptly.

Frequently Asked Questions (FAQ)

• Q: Is the 330709-000-040-10-11-00 a new and original probe?
  A: Yes, we supply only 100% new and original Bently Nevada probes.
• Q: What is the DC resistance of this probe?
  A: The DC resistance (RPROBE) is 5.9 ± 0.5 ohms for the 1.0-meter version.
• Q: What is the maximum recommended torque for the probe case?
  A: The maximum rated torque is 63.3 N•m (560 in•lb), but we recommend 21.1 N•m (187 in•lb).
• Q: How long does shipping take, and which carriers do you use?
  A: We ship within 5 days using FedEx, UPS, or DHL.
• Q: What is the operating temperature range for this probe?
  A: It operates from -52°C to +177°C (-62°F to +351°F).
• Q: What is the minimum shaft diameter recommended for this probe?
  A: The recommended minimum shaft diameter is 152 mm (6.0 in).
• Q: Can I return the probe if it does not fit my application?
  A: Yes, we accept returns within 30 days of delivery.
