330709-000-040-50-01-00 Bently Nevada 11mm Probe

Bently Nevada 3300 XL 11 mm Proximity Probe – Model 330709-000-040-50-01-00

Key Technical Specifications

• Brand: Bently Nevada.
• Model number: 330709-000-040-50-01-00.
• Product type: 3300 XL 11 mm Proximity Probe.
• Probe thread: M16 x 1.5 without armor.
• Unthreaded length: 0 mm (option 000).
• Overall case length: 40 mm (option 040).
• Total probe length: 5.0 meters or 16.4 feet (option 50).
• Important note for 5m probe: Use only with the five meter Proximitor Sensor.
• Connector type: Miniature coaxial ClickLoc with connector protector, standard cable (option 01).
• Agency approval: Not required (option 00).
• Probe DC resistance (RPROBE): 7.2 ± 0.8 ohms for 5.0m length.
• Recommended target diameter: minimum 30.5 mm (1.2 in) flat surface.
• Recommended shaft diameter: minimum 152 mm (6.0 in).
• Probe tip material: Polyphenylene sulfide (PPS).
• Probe case material: AISI 304 stainless steel (SST).
• Cable specification: 75 Ω triaxial, FEP insulated.
• Available total probe lengths: 1, 5, or 9 meters.
• Probe case torque (recommended): 21.1 N•m (187 in•lb).
• Probe case torque (max rated): 63.3 N•m (560 in•lb).
• Connector torque (max): 0.565 N•m (5 in•lb).
• Minimum bend radius: 25.4 mm (1.0 in) with or without SST armor.
• Maximum thread engagement length: 24 mm for M16x1.5.
• Operating and storage temperature: -52°C to +177°C (-62°F to +351°F).
• Low temperature caution: Exposure below -34°C (30°F) may damage the pressure seal.

Frequently Asked Questions (FAQ)

• Is this probe brand new and original?
  Yes, we supply only brand new and original Bently Nevada probes.
• Do you have stock for model 330709-000-040-50-01-00?
  Yes, we keep this 3300 XL 11 mm Proximity Probe in stock ready for shipment.
• What is your shipping time?
  We dispatch all orders within 5 business days after payment confirmation.
• Which shipping carriers do you use?
  We ship via FedEx, UPS, or DHL for fast and reliable delivery worldwide.
• Can I return this probe?
  Yes, we accept returns within 30 days from the delivery date.
• What does the connector protector do?
  The connector protector keeps the ClickLoc connector safe from dust and damage during handling.
• Why must I use a five meter Proximitor Sensor with this probe?
  The 5.0 meter cable length requires the matching five meter Proximitor Sensor for correct operation.
• What happens if I use this probe below -34°C?
  Exposing the probe below -34°C (30°F) may cause premature pressure seal failure.
• Can I bend the probe cable sharply?
  No, keep the bend radius at least 25.4 mm (1.0 in) to prevent cable damage.
