330881-28-04-050-06-02 PROXPAC XL Proximity Transducer

Bently Nevada 330881-28-04-050-06-02 - PROXPAC XL Proximity Transducer

This high-performance Proximity Transducer is made in the U.S.A. and includes an optional Certificate of Origin (COO).

Key Specifications:

• Weight: 1.44 kg (3.2 lb)
• Temperature Range: -51 °C to +177 °C (-60 °F to +350 °F)
• Power Requirements: -17.5 Vdc to -26 Vdc, maximum 12 mA consumption

Mechanical Ratings:

• Housing Rating: IP66 certified by BASEEFA
• Probe Material: AISI 304 stainless steel & Polyphenylene Sulfide (PPS)
• Probe Cable: 1-meter, 75 Ω triaxial, FEP insulated

Performance Features:

• Linear Range: 2 mm (80 mils), starting from 0.25 mm (10 mils)
• Scale Factor: 7.87 V/mm (200 mV/mil) ±5%
• Frequency Response: 0 to 10 kHz with 305 meters (1000 feet) of field wiring

Installation Options:

• Probe and Approvals: 3300 XL 8 mm probe with multiple approvals
• Standoff Adapter: 40 mm
• Fittings: Includes one 3/4-14 NPT fitting and reducer

Additional Information:

This transducer is designed to withstand harsh environments and provides reliable measurements. Ideal for critical monitoring applications.
