330908-00-19-10-02-05 Bently Nevada 3300 NSv Proximity Probe

Detailed Technical Specifications

• Product Identification: Manufacturer: Bently Nevada. Model: 330908-00-19-10-02-05 (3300 NSv Proximity Probe). This version includes multiple agency approvals (-05).
• Mechanical Configuration: It features a 3/8-24 UNF thread without armor. The overall case length measures 1.9 inches, with a total probe length of 1.0 meter (39 inches).
• Electrical Interface: This probe uses a miniature coaxial ClickLoc connector (-02) with standard cable for a secure and reliable connection.
• Measurement Performance: The linear range is 1.5 mm (60 mils) with a recommended gap of 1.0 mm (40 mils). It provides an incremental scale factor (ISF) of 7.87 V/mm (200 mV/mil).
• Linearity & Accuracy: Deviation from best fit straight line (DSL) is less than ±0.06 mm (±2.3 mils), ensuring precise readings.
• Frequency Capability: The system frequency response is 0 to 10 kHz (+0, -3 dB) typical with up to 305 meters of field wiring.
• Environmental Ratings: Operating temperature range is -52°C to +177°C (-62°F to +351°F). The probe tip uses Polyphenylene sulfide (PPS) with an AISI 304 stainless steel case.
• Electrical Characteristics: Probe DC resistance (center to outer conductor) measures 4.2 ± 0.5 ohms for this 1.0-meter length.
• Installation Guidelines: Hand tighten only; maximum recommended torque is 0.56 N•m (5 in•lb). The minimum bend radius is 25.4 mm (1.0 in).

Frequently Asked Questions (FAQ)

• Will this 330908-00-19-10-02-05 work with my existing extension cable?
  Yes, this 3300 NSv Proximity Probe is fully compatible and interchangeable with Bently Nevada's previous 3300 RAM extension cables.
• What is the difference between the -01 and -02 connector options?
  The -02 option on this probe indicates a miniature coaxial ClickLoc connector without the additional connector protector found on -01 versions.
• What are the recommended field wiring specifications?
  We recommend a three-conductor shielded triad cable (16 to 24 AWG) up to 305 meters (1000 feet) from the proximitor.
• What is the minimum target size for this probe?
  The recommended minimum target diameter is 13 mm (0.5 inches) for optimal linearity and scale factor stability.
• How quickly can you ship this item?
  We have this specific 3300 NSv model in stock and typically dispatch orders within 5 days via DHL, UPS, or FedEx.
