3500/94M-05-00-01 3500/94M VGA Module Bently Nevada

Reliable 15" VGA Display for Critical Machinery

The Bently Nevada 3500/94M-05-00-01 VGA Display Module offers a clear, industrial‑hardened interface for your 3500 monitoring system. This 15‑inch unit mounts in a standard 19‑inch rack and provides real‑time access to machine data. Engineers trust this module for its robust construction and precise signal handling.

Key Specifications & Performance

• Brand & Model: Bently Nevada 3500/94M-05-00-01 (15" display, 19" rack mount).
• Power Efficiency: Consumes only 4.6 watts maximum. Operates on 24 Vdc (permissible range 12–24 Vdc).
• Environmental Resilience: Works from –20°C to 65°C (–22°F to 149°F) and withstands 95% humidity (non‑condensing).
• Approvals: Carries CSA/NRTL/C Class I, Division 2 certification for hazardous areas.
• Connectivity: Includes VGA port, RS232 touch controller interface, and front port for 24 Vdc power/VGA/touch.

Advanced Touch Display & Physical Details

• Advantech FPM-8151H panel: 15" diagonal, LED backlight, resistive touch. IP65-rated front protects against dust and water.
• Industrial Hardening: Designed for continuous operation from 0°C to 60°C (32°F to 140°F).
• Complete Assembly Dimensions: Module 241.3 x 24.4 x 241.8 mm (9.5 x 0.96 x 9.52 in); display 422 x 338 x 68 mm (16.61 x 13.31 x 2.68 in).
• Lightweight Components: Monitor module 0.73 kg (1.6 lb), I/O module 0.34 kg (0.75 lb), display 8.5 kg (18.75 lb).

System Integration & Rack Space

• Required Partner Module: Works with 3500/22 Transient Data Interface (TDI) – firmware Rev 1.71 or newer.
• Rack Allocation: Monitor module occupies one full‑height front slot; I/O module uses one full‑height rear slot.
• KVM Extender Notes: Receiver approved for Class I, Div 2; transmitter must stay in safe area or purged enclosure.
• Compliance: Meets EMC standards EN 61000-6-2/6-4, electrical safety CSA C22.2 61010-1 / UL EN 61010-1, and RoHS.

What’s Included & Shipping Information

• In the box: 3500/94M-05-00-01 monitor module, I/O module, and 15" Advantech display with 24 Vdc power supply.
• Shipping methods: We ship via FedEx, UPS, or DHL – fast and trackable worldwide.
• Warranty: Two‑year manufacturer warranty (display) and Bently Nevada standard warranty for electronics.

Frequently Asked Questions

Q: Can I use the 3500/94M-05-00-01 in a cold environment?
A: Yes, the electronics operate down to –20°C, but the LCD screen requires 0°C minimum. If temperatures fall below freezing, use a heated enclosure for the display.

Q: Which Bently rack software versions do I need?
A: You need 3500/94M firmware 4.06 Rev. C, 3500/22 TDI Rev 1.71, and rack config software Rev 5.6 or newer.

Q: Is the touch screen usable with gloves?
A: Yes, the Advantech resistive touch interface works with gloved hands and in industrial environments.

Q: What is the difference between the 3500/94M and a standard office monitor?
A: This module provides rugged construction, Class I Div 2 certification, and seamless integration with 3500 monitoring data – not just a generic display.

Q: Do I need to order the KVM extender separately?
A: The 3500/94M-05-00-01 comes without the KVM extender (option "00"). Order the extender kit separately if you need remote display placement.

Q: What is the inrush current of the display?
A: Inrush current is 2.62 A at 24 V for less than 500 µs; normal operating current stays below 500 mA.
