ABB 3BSE081636R1 Redundant Processor Unit PM862K02

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (16 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Technical Specifications

Parameter Details
🔢 Article Number 3BSE081636R1 (PM862K02)
🔒 Redundancy Yes
⚙️ High Integrity No
⏱️ Clock Frequency 67 MHz
💾 Memory 32 MB
📊 RAM Available for Application 23.521 MB
💾 Flash Memory for Storage Yes

Detailed Data

Parameter Details
🔍 Processor Type MPC866
⏳ Switch Over Time in Red. Conf. Max 10 ms
🔄 No. of Applications per Controller 32
📑 No. of Programs per Application 64
📊 No. of Diagrams per Application 128
🛠️ No. of Tasks per Controller 32
🔄 Number of Different Cycle Times 32
⏱️ Cycle Time per Application Programs Down to 1 ms
💻 Flash PROM for Firmware Storage 4 MB
🔌 Power Supply 24 V d.c. (19.2-30 V d.c.)
⚡ Power Consumption +24 V typ/max 210 / 360 mA
💡 Power Dissipation 5.1 W (8.6 W max)
🔋 Redundant Power Supply Status Input Yes
🔋 Built-in Back-up Battery Lithium, 3.6V
🕒 Clock Synchronization 1 ms between AC 800M controllers by CNCP protocol
📅 Event Queue in Controller per OPC Client Up to 3000 events
🌐 AC 800M Transm. Speed to OPC Server 36-86 events/sec, 113-143 data messages/sec
🔗 Comm. Modules on CEX Bus 12
⚡ Supply Current on CEX Bus Max 2.4 A
🔌 I/O Clusters on Modulebus with Non-Red. CPU 1 electrical + 7 optical
🔌 I/O Clusters on Modulebus with Red. CPU 7 optical
📦 I/O Capacity on Modulebus Max 96 (single PM862) or 84 (red. PM862) I/O modules
⏳ Modulebus Scan Rate 0 - 100 ms (actual time depending on number of I/O modules)
⚡ Supply Current on Electrical Modulebus 24 V : max 1.0 A
⚡ Supply Current on 5V Modulebus 5 V : max 1.5 A
🌐 Ethernet Channels 2
