AC Output Module | Allen-Bradley 1746-OA8

Bulk Orders & Fast Shipping

Instant 10% Discount On Winter Banks Credit/Debit Cards EMI and CreditCard

Fast & Reliable Worldwide Shipping – Ready to Dispatch from Stock
In stock (14 units), ready to be shipped
  • Fast shipping
  • Return Policy
  • Lowest Price
  • Help Center 24/7

About the Product

Allen-Bradley 1746-OA8 AC Output Module

Core Specifications
Output Configuration 8 channels (2 groups of 4)
Voltage Range 85-264VAC (47-63Hz)
Current Capacity 1A/channel @30°C, 0.5A @60°C
Module Current 8A @30°C, 4A @60°C
Switching Speed 1ms ON / 11ms OFF
Electrical Characteristics
Backplane Current 185mA @5VDC
On-State Voltage Drop ≤1.5V @1A
Surge Current 10A for 25ms
Physical Specifications
Connection Type Removable terminal block
Isolation Optical isolation
Indicators Per-channel status LEDs
Environmental Ratings
Operating Temperature 0-60°C (32-140°F)
Storage Temperature -40-85°C (-40-185°F)
Humidity 5-95% non-condensing

Typical Applications

  • Industrial lighting control systems
  • Small motor starters
  • AC solenoid activation
  • HVAC equipment control
  • Conveyor system components
